4. Placing the Graphic in a Format
4-3
col Distance between the left edge of the print area on the supply and the left
edge of the graphic. Use the units of measure specified in the Format
Header.
Unit of Measure 9490/9494/9446/1460 6030
English 0- 399 0- 183
Metric 0- 1015 0- 465
Dots 0- 768 0- 352
NOTE: The column specified in the Constant Text, Bitmap, Line, or Box
field is added to the col value above to determine the actual position
in the format.
mode Imaging mode. Enter 0. This is the only option supported by these printers.
rotation The orientation of the graphic on the supply. Only 0 is supported by these
printers.
Example {G,57,0,0,0,0¦}
♦ Graphic field
♦ Image is identified by number 57
♦ Image begins at 0,0
♦ Imaging mode is 0
♦ Rotation is 0
