MPCLII Graphics Manual
3-4
row Distance between the bottom of the graphic image area and the first bitmap
line. This is usually 0, unless you want a fixed amount of white space around
the graphic image. Refer to “Positioning the Graphic Image,” earlier in this
chapter for more information. Must be measured in selected units.
col Distance between the left edge of the graphic image area and the left edge of
first bitmap line. This is usually 0, unless you want a fixed amount of white
space around the graphic image. Refer to “Positioning the Graphic Image,”
earlier in this chapter for more information. Must be measured in selected
units.
mode Imaging mode. Enter 0. This is the only option supported by these printers.
“name” Assign a name (for reference only) to the graphic. The name must be 1 - 8
characters in length. Enclose in quotation marks (example: “Name").
Example {G,99,A,R,G,0,0,0,"99Wire"¦
♦ Graphic header
♦ Image is identified by number 99
♦ Image being Added
♦ Image stored in volatile RAM
♦ Image uses Graphic (dot) measurement
♦ Image will be placed according to the row and column parameters
specified in the Graphic Field within the format.
♦ Imaging mode is 0
♦ Image is called 99Wire
