3. Creating a Graphic Packet

3-11

Sample Hex Graphic Packet _________________________________

{G,99,A,R,G,0,0,0,"99WIRE"¦

B,39,48,H,"3FFFFFF0"¦

B,40,32,H,"01FFC000000FF8"¦

B,41,32,H,"3E00000000000FC0"¦

B,42,24,H,"03C0003FFFFFF0000F"¦

B,43,24,H,"7C3FFFFFFFFFFFFFE1F0"¦

B,44,16,H,"0183FFFFFFFFFFFFFFFF06"¦

B,45,16,H,"018FFFFFFFFFFFFFFFFFFE"¦

B,46,16,H,"01FFFFFFFFFFFFFFFFFFFE"¦

B,47,16,H,"01FFFFFF80001FFFFFFFFE"¦

B,48,16,H,"01FFFFF0000000007FFFFC"¦

B,49,24,H,"7F800007FFFF00003FF0"¦

B,50,24,H,"1FC00007FFFF00001FC0"¦

D,0,4,4¦

B,51,24,H,"1C03FFFFFFFFFFFE01C0"¦

D,0,4,4¦

B,52,32,H,"3FFFFFFFFFFFFFE1C0"¦

D,0,4,4¦

B,53,24,H,"03FFF0000000007FFE"¦

D,0,4,4¦

B,70,0,H,"0400001FC00007FFFF00001FC0"¦

B,71,0,H,"0600001C03FFFFFFFFFFFE01C0"¦

B,72,0,H,"030000003FFFFFFFFFFFFFE1C0"¦

B,73,0,H,"01000003FFF0000000007FFE"¦

B,74,8,H,"FC001C03FFFFFFFFFFFE00C0"¦

B,75,8,H,"FE00003FFFFFFFFFFFFFE0C0"¦

B,76,8,H,"1FF803FFF0000000007FFE"¦

B,77,8,H,"0FFFCFFC00000000000001C0"¦

B,78,16,H,"FFDF000FFFFFFFFF8003C0"¦

B,79,16,H,"7FFFC00007FFFF00001FC0"¦

B,80,24,H,"1C03FFFFFFFFFFFE01C0"¦

D,0,4,4¦

B,81,32,H,"3FFFFFFFFFFFFFE1C0"¦

D,0,4,4¦

B,82,24,H,"03FFF0000000007FFE"¦

D,0,4,3¦

B,83,24,H,"1FC00007FFFF00001FC0"¦

D,0,4,3¦
