Chapter 4. Placing the Graphic in a Format

The graphic image may be a bitmapped graphic or a compliance label overlay.

To include a graphic within a format:

1. Design the graphic image as shown in Chapter 2, “Designing the

Graphic Image.”

2. If you are using RAM, place a Graphic Field in the format file to

reference the graphic. Refer to the following section, “Including the
Graphic Field,” for more information.

NOTE: If you are using temporary storage, you do not need a

Graphic Field in your format to reference the graphic image.

3. Download all the necessary packets (check digit, format, etc.).

NOTE: If you are using the 6030 printer, you must define a script

instead of a batch.

4. Send the graphic file to the printer, if you have not already done so.

Refer to Chapter 3, “Creating a Graphic Packet,” for more
information.
