SpectraLink 8000 Telephony Gateway Administration Guide
System Diagram
1725-36028-001_T.doc
optional
SpectraLink 8000
Telephony Gateway
SpectraLink 8000
Telephony Gateway
SpectraLink 8000
Telephony Gateway
SpectraLink 8000
Telephony Gateway
SpectraLink 8000
Telephony Gateway
SpectraLink 8000
SVP Server
Ethernet switch
Access point
Administrative
computer
Wireless
Telephones
Access point
Wireless
POS
PBX
Demarc block
CAT 5 cable
25 pair cable
Multiple phone cables
Phone cable
Device supplied
y Polycom
b
desksets
Five SpectraLink 8000 Telephony Gateways with SpectraLink 8000 SVP Server example
