Chapter 5 Preparation
58
5-1 Supplying the power
A battery pack or an AC power source can be used as this
unit’s power supply.
To use the battery pack, there is the following
choice of makes of batteries:
≥ Anton-Bauer
≥ IDX
≥ Sony
≥
Batteries of other makes can also be supported by changing
the setting menu but no guarantees are made for the
system when they are actually used with this unit.
≥ Before using the battery pack, recharge the battery using
the battery charger.
(For details on the recharging method, refer to the operating
instructions of the battery concerned.)
5-1-1 Attaching the battery and setting the
battery type
Using the Anton Bauer battery pack
1
Attach the battery pack made by Anton Bauer.
2 Insert the battery pack and slide it in the direction of the
arrow.
Battery pack made
by Anton Bauer
A battery holder made by Anton Bauer is equipped with a
power output connector for the lighting and a lighting control
switch to enable a light to be easily attached. For details on
the lighting systems available, contact Anton Bauer.
3
Set the battery type.
Select the battery type using the BATTERY SELECT
menu item. This item is selected from the
screen on the VTR FUNCTION page.
For details, refer to “7-8-3 BATTERY SETTING1.”
Anton Bauer batteries which can be used
O PRO14
O TRIM14
O HYTRON50
O HYTRON100
O DIGITAL14
O DIGITAL13
O DIONIC
To remove the battery pack, slide it in the opposite direction to
the one in which it was attached while keeping the release
lever on the battery holder pulled down all the way.
Release lever
#< BATTERY/TAPE >
BATTERY SELECT :DIONIC
EXT DC IN SELECT :AC-ADPT
BATT NEAR END ALARM :OFF
BATT NEAR END CANCEL:ON
BATT END ALARM :ON
BATT REMAIN FULL :70%
TAPE NEAR END ALARM :ON
TAPE NEAR END TIME :2min
TAPE END ALARM :ON
TAPE REMAIN/∫
:3min/∫
Power output connector for lighting
Lighting control
switch
