PLANET Technology Corp. GRT-101/401 User ’s Manual
- - 11
Web UI Configuration
After connection via web browser,
click Bridge to setup Bridging mode of the
Router and then click Next for the next setting.
Enter WAN1 VPI: 0 and VCI: 33.
Select WAN1 AAL5 Encap: LLC
Enter LAN IP: 192.168.0.1
Enter LAN Sub-net Mask: 255.255.255.0
Enter Gateway: 192.168.0.254 The Gateway
is directly pointed to the BAS IP.
Click Next
Click OK to write the new configuration data
to the flash memory of GRT-101/GRT-401.
Note: You have to do that otherwise the new
configuration parameters will not affect
GRT-101/GRT-401.
Click Restart GRT-101/GRT-401 will reboot
with the new setting.
Console Configuration
Do the following steps:
1 User : admin É password: admin É
2 enable É supervisor password: root É
3 setup
É mode É
Bridge
É
4 wan É Interface number (1~8) : 1 É
Protocol É : Ethernet É
vpi_vci : 0 Й
33
Й
encap : LLC
É
5 bridge É gateway Й 192.168.0.254 Й
6 lan ÉaddressÉ 192.168.0.1 Й
255.255.255.0 Й
7 (back to root) write
É y É
y É(reboot)
