Page 7
Ge
tt
in
g
s
ta
rte
d
7
RQT6570
U
Remote control signal sensor . . . . . . . . . . . . . . . . . . . . . . . 10
V
PC card slot (PC CARD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
W
Card eject button (EJECT) . . . . . . . . . . . . . . . . . . . . . . . . . . 25
X
Disc tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Y
HDD record lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Z
DVD record lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
[
L2 input terminals (L2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
\
DV input terminal (DV INPUT). . . . . . . . . . . . . . . . . . . . . . . . 58
]
Display
^
Channel buttons for recorder (
X
W
, CH) . . . . . . . . . . . . . . . 19
_
Skip/Slow/Search buttons (
4
,
5
) . . . . . . 24, 29
A
Timer recording display
On:
When timer recording is on standby (
➜
page 34)
Flashes: When the unit couldn’t go to timer recording standby
B
Disc type
C
The display mode of the main display section
TITLE:
Title number
CHAP:
Chapter number
TRACK:
Track number
PG:
Program number
PL:
Play list number
D
Recording mode (
➜
page 19)
E
DVD indicator
Flashes: When you press [
Í
, DVD POWER] to turn the unit off
until it actually turns off
F
Card indicator
On:
When a PC card is set in the unit (
➜
page 25)
Flashes: When a PC card is being read/written to
G
Dubbing direction indicator
H
Channel
I
Main display section
Recording and play counter, and other miscellaneous messages
[Note]
A half mirror is used for the unit display so the display may occasion-
ally be difficult to see depending on surrounding conditions.
Main unit
FUNCTIONS
TIME SLIP
U
1
X Y
Z
V
W
^
]
\
[
_
? 7 8 K :
M
O
;
F
G
6
6
Controls such as
1
function the same as the buttons on the remote control.
The unit’s display
A
B
E
F
H
D
C
G
I
Center circle (e.g., DVD-RAM)
Rotating (REC):recording
Stopped (REC):recording paused
Rotating (REC, PLAY):
Chasing play or simultaneous
rec and play is in progress
Rotating (PLAY):playing
Stopped (PLAY):play paused
“PLAY” flashes:
the resume function (
➜
page 23)
is working
