4
1 POWER . : to switch the TV on and off.
The power remains on even when the Power
switch is turned off.
2 VOLUME –/+: to adjust sound level.
3 MENU : to access or close menus.
The PROGRAM –/+ keys can be used to
select a menu item and the VOLUME – / +
key to enter into the selected menu item
and make adjustments.
4 PROGRAM / CHANNEL –/+ : to select
programmes.
5 POWER socket : Insert the mains plug
into a wall socket.
6 DVI Audio Input : for connecting a HD
(high definition) equipment or computer with
DVI output.
7 Component Video Inputs / Audio Inputs :
to connect to equipment like DVD, Set-top
box which have the same sockets. Connect the
audio inputs of the TV to the outputs of the
device together with the Component Video
Inputs.
8 CI (Common Interface) slot : to connect
a CAM (Conditional Access Module) and a
smartcard.
9 DATA socket : for Service use only.
NOTE
For more details on connections,
see CONNECTION GUIDE.
10 SPDIF socket : to connect to an amplifier
with coaxial digital input (only available in
Digital Mode).
11 HDMI 1 /HDMI 2 sockets : to connect to
set-top boxes, DVD player/recorder, High
Definition receiver/equipment or Personal
Computer.
12 EXT1 and EXT2 socket : connect to equipment
like DVD player/recorder, VCR, Decoder box
which have scart connections.
Important : In order to connect your
decoder box , please use EXT1 scart only.
13 TV Aerial socket : Insert the aerial plug into
the 75 Ω : (TV antenna) socket .
14 Side connections : for connecting to devices
like video camera or camcorder. Also allows
you to connect your headphone for your
personal listening pleasure.
Television keys and connectors
