Page 33

PIP

PIP Size

Horizontal

Vertical

HDMI

Supported PC Resolutions

640 x 480, 60 Hz

800 x 600, 72 Hz

640 x 480, 67 Hz

800 x 600, 75 Hz

640 x 480, 72 Hz

1024 x 768, 60 Hz

640 x 480, 75 Hz

1024 x 768, 70 Hz

800 x 600, 56 Hz

1024 x 768, 75 Hz

800 x 600, 60 Hz

Using the TV as a PC Monitor

Your TV can be used as a computer monitor.

IMPORTANT
For the TV to function as PC monitor, the
following steps must be taken :

HDMI 1 or HDMI 2 input MUST be

connected to the DVI output of the PC.

Use a DVI to HDMI adaptor to do the

connection.

Press the

key to

display Source List and

use the О п key

to select

HDMI 1 or HDMI 2

Use

the Æ /

key to

switch to the selected

source.

Using the PC menus

Press the

key to display the PC menu.

Use the О п key to access the settings

and the Н Ж key to select or adjust setting

(the settings are automatically saved):

Description Picture settings

Brightness / Contrast :
– Adjusts the brightness and contrast.
Colour Temp :
– Changes the colour rendering : Cool (bluer),

Normal (balance) or Warm (redder).

Audio Selection :

– Chooses the sound reproduced on the TV (PC

or TV).

Source

EXT1
EXT2 / SVHS2
AV / SVHS3
EXT 4
HDMI 1
HDMI 2
DIGITAL TV

Source

EXT1
EXT2 / SVHS2
AV / SVHS3
EXT 4

HDMI 1

HDMI 2
DIGITAL TV

NOTE

For more details on connection to the

PC equipment, see CONNECTION

GUIDE.

NOTE : PC connection is only available via HDMI / DVI connector.

VGA connection is not supported.

Description of Features
Format :
– Chooses between full screen or native format
of the PC screen.

PIP (Picture-in Picture) :
– Displays a PIP screen to watch TV programmes
at the same time.

* Mode Selection :
– When you connect PC or HD equipment
supporting resolutions of 480p, 576p or 720p,
the Mode Selection in the Features menu
will be highlighted. This will allow you to select
between the PC and HD mode. If it does not
support the 480p, 576p or 720p resolutions,
you cannot access this function.

Using the PIP feature
The PIP (Picture-in-Picture) feature allows you to
call up a PIP screen of a TV programme while you
are in PC mode.
IMPORTANT
To call up a PIP screen of the TV programme, the

following step must be taken :

HDMI-1 or HDMI-2 input MUST be connected to

the DVI output of the PC equipment. Use a HDMI

to DVI adaptor cable to do the connection.

The PIP menu items : PIP Size, Horizontal
and Vertical works in exactly the same way as
when calling a PIP screen in TV mode. Except for
HDMI, there is no selection for other source.

For description of PIP menu items and how it

works, refer to the section on “Using the PIP
(Picture-in Picture) Feature” page 24.

No Selection
