Introduction
Top View
To open the LCD display:
1.
Place the computer on a stable surface.
2.
Move the LCD latches
in the direction of the arrows to release the top cover
(the left latch will lock in position and is clearly marked with locked
and
unlocked
icons).
3.
Lift the top cover to reveal the LCD panel and keyboard.
4.
Adjust the LCD panel to a comfortable viewing angle.
5.
The LED indicators
show the power and battery status of the computer, and
give notification of e-mail received.
2
1
1
Figure 1 - 1
Top View
(LCD Panel Closed)
1.
LCD Latches
2.
LED Power &
Communication
Indicators
1
2
