Mounting and Adjusting the Lens
Mounting the Lens
1
Raisethelensclampingleverandremovethe
mountcap.
MountCap
LensClampingLever
2
Tomountthelens,aligntheindentationatthe
topcenterofthelensmountwiththecenter
markofthelens.
Mark
3
Lowerthelenslevertofirmlytightenthelens.
4
Securethecablethroughthecableclamp,and
plugitintotheLENSconnector.
LENSConnector
Cable
clamp
5
Adjustthelensflangeback.
For details, refer to [Adjusting the Lens Flange
Back] (page 90).
 NOTE
• Please refer to the lens instruction manual for
guidance on lens handling.
• When the lens is removed, install the mount cap to
protect the device.
