1
Chapter
11
Specifications
LENS
1 RET-SW
2 REC
3 GND
4 IRIS-AUTO
5 IRIS-CONT
6 UNREG+12V (Max 0.4 A)
7 IRIS-POSI
8 IRIS-G-MAX
9 EXT-POSI
10 ZOOM-POSI
11 FOCUS-POSI
12 SPARE
Panasonic Part No. K1AY112JA001
Manufacturer Part No. HR10A-10R-12SC (71)
(Hirose Electric Co.)
1
2
4
5
6
7
8
9
10
11 12
3
Wireless receiver interface
1 CHSHIELD GND
CH-1HOT Audioinputfromawireless
receiver:CH1HOT
CH-1COLD Audioinputfromawireless
receiver:CH1COLD
GND GND
+1VUNREG Powersupplyforawirelessreceiver
RXON Remotepoweroutputtoawireless
receiver.
FRWARN RFwarninginputfromawireless
receiver
RM Notused
RM Notused
10 SPARE1 Notused
11 SPARE Notused
1 EXTCLK Notused
1 CLKSHIELD Notused
1 CH-SHIELD GND
1 CH-HOT Audioinputfromawireless
receiver:CHHOT
1 CH-COLD Audioinputfromawireless
receiver:CHCOLD
1 +.V Powersupplyforawirelessreceiver
1 VIDEOOUT Notused
1 VIDEORET Notused
0 VIDEOEN Notused
1 RM1(RMCLK) Notused
RM(RMDATA) Notused
RM(RMWR) Notused
RM+V Notused
RMGND Notused
Panasonic Part No. K1GB25A00010
Manufacturer Part No. HDBB-25S (05)
(Hirose Electric Co.)
13
25
1
14
