Specifications
ELECTRICAL/VIDEO
Input Voltage:
100-240 VAC +10%, 50/60 Hz, autoranging*
Power Consumption:
Maximum 350 watts
Signal System:
NTSC/PAL
Operating System:
Windows XP Embedded only
Recording Resolutions:
NTSC
PAL
320 x 240
320 x 288
640 x 240
640 x 288
640 x 480
640 x 576
352 x 240
352 x 288
704 x 240
704 x 288
704 x 480
704 x 576
Compression:
Pelco proprietary
Video Inputs:
8/16/24/32 (looping with automatic termination)
VGA Outputs:
1
Analog Video Outputs:
1 with DX8108 and DX8116
2 with DX8124 and DX8132
Alarm Input Terminals:
8/16/24/32 (user selectable N.O./N.C.)
Relay Output Terminals:
8/16/24 (user selectable, N.O./N.C.)
Relay Contact Ratings**
Rated (Resistive) Load:
0.5 A at 120 VAC or 1 A at 24 VDC
Remote Administration:
Full remote control via TCP/IP network
Total Recording Rate:
Up to 480 images per second at CIF
Up to 240 images per second at 2CIF
Up to 120 images per second at 4CIF
MECHANICAL
Connectors
BNC:
Video inputs and outputs
6-Pin Mini-DIN:
PS/2 mouse and keyboard
DB9:
COM 1
DB15:
VGA port
DB26:
Optional audio option
RJ-45:
10/100/1000 megabit Ethernet port and RS-485/RS-422 ports
Audio Connectors:
3 miniature phone jacks: line in, microphone in, and audio out
USB:
6 high-speed USB 2.0 ports (2 in front, 4 in rear)
ENVIRONMENTAL
Operating Temperature:
50° to 95°F (10° to 35°C)
Relative Humidity:
Maximum 80%, noncondensing
GENERAL
Dimensions
Desktop:
19.9 (D) x 17.0 (W) x 7.0 (H) inches (50.55 x 43.18 x 17.78 cm)
Rack Mount:
22.0 (D) x 19.0 (W) x 7.0 (H) inches (55.88 x 48.26 x 17.78 cm)
Unit Weight:
47 lb (21 kg) maximum (fully equipped, 32 channel unit)
Shipping Weight:
68 lb (31 kg) maximum (fully equipped, 32 channel unit)
*It is recommended that an uninterruptible power supply (UPS) device be used with the DX8100 with a 700 VA or better rating.
**Relays are grounded.
(Design and product specifications subject to change without notice.
