NXP Semiconductors
TDA5051A
Home automation modem
4. Quick reference data
[1] The value of the total transmission mode current is the sum of I
DD(RX/TX)(tot)
+ I
DD(PAMP)
in the Table 5 “Characteristics” .
[2] Frequency range corresponding to the EN50065-1 band. However, the modem can operate at any lower oscillator frequency.
[3] The minimum value can be improved by using an external amplifier; see application diagrams Figure 19 and Figure 20 .
5. Ordering information
Table 1. Quick reference data
Symbol Parameter Conditions Min Typ Max Unit
V
DD
supply voltage 4.75 5.0 5.25 V
I
DD(tot)
total supply current f
osc
= 8.48 MHz
Reception mode - 28 38 mA
Transmission mode;
DATA_IN = 0; Z
L
= 30
Ω
[1] - 47 68 mA
Power-down mode - 19 25 mA
f
cr
carrier frequency [2] - 132.5 - kHz
f
osc
oscillator frequency 6.08 - 9.504 MHz
V
o(rms)
output carrier signal (RMS value) DATA_IN = LOW;
Z
L
= CISPR16
120 - 122 dB
μV
V
i(rms)
input signal (RMS value) [3] 82 - 122 dB
μV
THD total harmonic distortion on CISPR16 load
with coupling network -
−55
- dB
T
amb
ambient temperature
−50
- +100
°C
Table 2. Ordering information
Type number Package
Name Description Version
TDA5051AT SO16 plastic small outline package; 16 leads; body width 7.5 mm SOT162-1
