INSTALLATION
EATON Powerware ® 9135 Two−in−One UPS (5000/6000 VA) User’s Guide S 164201726 Rev 1
www.powerware.com
45
BATT. NO.
200
−250V~,24A
RPO RS−232
CAUTION: DO NOT DISCONNECT BATTERY CABLE UNDER LOAD
BATTERY CONNECTOR
180VDdc
(4) L6−30 Receptacles
Communication Bay
Relay Port
RPO Port
EBM RJ−11 Connector
Output Terminal Block
Input Cord with L6−30P
EBM Battery Connector
USB Port
RS−232 Port
Figure 28. 5000/6000 VA, U Models
