Setting Up the VMC 1000 Appliance
Polycom, Inc.
9
Rear Panel Connections
Connect Cables
1
Connect the power cords.
2
Connect the Ethernet cable to port 1.
USB Port
Mouse Port
Keyboard Port
Two Power
Cords
AC Power
Inlets
Serial Port
PCI Expansion Slots
VGA Port
Ethernet Cable
Network Interface
Connector
2
1
Power Supply
Locks
Power Good
LEDs
NOTE: Both power cords need to be plugged into the appliance. If they are not
both plugged in there is an alarm that sounds providing an alert that there is an
issue with the unit
