Video Media Center - VMC 1000 Getting Started Guide

6

Polycom, Inc.

Mechanical Loading - Mounting of the equipment in the rack should be

such that a hazardous condition is not achieved due to uneven

mechanical loading.

All racks must be mounted securely. Ensure that all leveling jacks or
stabilizers are properly attached to the rack. If installing multiple
appliances in a rack, make sure the overall loading for each branch circuit
does not exceed the rated capacity.

Do not slide more than one appliance out from the rack at a time.
Extending more than one appliance at a time may result in the rack
becoming unstable. Install your appliance in the lower part of the rack
because of its weight and also for ease in accessing appliance components.

Circuit Overloading - Consideration should be given to the connection of

the equipment to the supply circuit and the effect that overloading of the
circuits might have on overcurrent protection and supply wiring.
Appropriate consideration of equipment nameplate ratings should be

used when addressing this concern.

Reliable Earthing - Reliable earthing of rack-mounted equipment should

be maintained. Particular attention should be given to supply connections
other than direct connections to the branch circuit (e.g. use of power

strips).

Install near appropriate AC outlets, and Ethernet hubs or individual jacks.

Be sure to install an AC

Power Disconnect for the entire rack assembly. The

Power Disconnect must be clearly marked.

Ground the rack assembly

properly to avoid electrical shock.

Rack Installation

4-Post Rack Installation

Unpack the appliance and locate the mounting hardware.

NOTE: The following installation procedures for are for use with the rails and
hardware provided in your ship kit. If different style rails are being used, or if your
rack requires different hardware, refer to the instructions provided with your rail or
rack ship kit.

NOTE: When removing the appliance from the 4-post rack, you will need to press
down on the right locking tab and lift up on the left locking tab in order to release it
from the rack. Carefully slide it out supporting the unit on both sides at all times.
