Setting Up the VMC 1000 Appliance
Polycom, Inc. 7
Step 1
• Locate the two rack rail brackets that came in your ship kit.
• Attach the medium-sized adjustable rack bracket to the longer fixed rack
bracket as shown.
• Insert the tab on the rear of the medium adjustable rack bracket through
the larger round opening on the back end of the long fixed rack bracket
and slide the long bracket forward to keep the two brackets from coming
apart. These rail brackets slide to accommodate different rack depths.
Step 2
• Insert a cage nut into each of the square holes in the rack you will be using
as shown (three in the front and two in the rear). They click into place.
• Attach the rack /rail assemblies to the rack using two M5 x 12 flat head
screws and cone washers in the front and back. The convex side of the cone
washers face toward the rack.
• Make sure the rack / rail assemblies and screws are aligned in the rack not
only in the front and back, but are level in height on the left and right sides
for proper alignment for appliance installation.
Step 3
• Align the fixed chassis rails on the appliance with the fixed rack rail
brackets installed in the rack.
• Carefully slide the appliance into the rack until you hear the locking tabs
on each side of the fixed front rails click into place.
• Push the appliance all the way into the rack until it stops.
• Sefcure the unit in the rack using a 10-32 x 3/4" truss head screw (and a
cage nut if not already installed) in the center hole on each rail.
2-Post Rack Installation
Unpack the appliance and locate the mounting hardware.
NOTE: The following installation procedures are for use with the rails and hardware
provided in your ship kit. If different style rails are being used, or if your rack
requires different hardware, refer to the instructions provided with your rail or rack
ship kit.
