Liquid Crystal Display (LCD)
35
Using The Control Panel
Legend:
1) Status Indicators
2) Liquid Crystal Display (LCD)
3) Paper Path Diagram
4) Function Keys
Figure 7: Control Panel
The control panel (Figure 7), is located on the top right side of the
front cover.
The LCD, status indicators, and function keys are described in the
following sections.
Liquid Crystal Display (LCD)
The liquid crystal display (LCD) displays messages, printer
operating status, configuration options, and error codes.
Status Indicators
The status indicators display the current operational status of the
printer.
JOB IN
PROCESS
STAND BY LINE
SYNC
SYS
AVAIL
ONLINE FAULT
ONLINE CLEAR TEST SHIFT
CANCEL
PAGE
EJECT
ENTER
PREV
UP
NEXT
DOWN
1
2 3
4
