Centronics parallel interface configuration – Printronix L5020 User Manual
Page 230
Appendix
Interfaces
232
Centronics Parallel Interface Configuration
The printer is configured for the Centronics interface via the
Centronics Interface menu, as described on page 66. The following
interface configuration parameters may be modified to meet
specific application requirements:
Data Bit 8
Enable* or Disable
Paper Inst Line
Enable or Disable*
Data Polarity
Standard* or Inverted
Strobe Polarity
Standard* or Inverted
ACK Polarity
Standard* or Inverted
Busy Polarity
Standard* or Inverted
Slct (Select) Polarity
Standard* or Inverted
Fault Polarity
Standard* or Inverted
Paper Instr Pol
Standard* or Inverted
PE Polarity
Standard* or Inverted
NFAULT/PE Clt
Act Together* or Act Separate
* = Factory default setting
