Chapter 5 Major Cleaning
168
CAUTION When wiping the SELFOC
®
lens, be certain not to apply
excessive force to the drum surface potential sensor located
near the SELFOC lens, as this may cause the sensor to be
dislocated. (If this happens, contact your service
representative.)
12. Wipe the SELFOC lens by moving a Toraysee cloth (See page
136) from the inner part of the printer toward you. Wipe the lens
in this manner several times until there is no more dirt on the
cloth.
NOTE: Always wipe the SELFOC lens with the unused side of the
Toraysee.
Legend:
1) SELFOC Lens
2) Drum Surface Potential Sensor
13. Install the main charger.
14. Install the photoreceptor drum. (See page 115.)
15. Install the developing unit. (See page 130.)
16. Install the cleaning unit.
2
1
