5 • Troubleshooting and maintenance
Model 6511RC User Manual
86
Matrix Switch test tools
Matrix Switch test tools
For the purpose of testing and troubleshooting the STM-1 link, the DS0 Mapping definitions, and H.110 bus
connectivity, the Model 6511RC Matrix Switch offers the following tool sets:
•
Loopback test modes for the Matrix Switch STM-1 port
•
SDH Section Trace and SDH Path Trace functions for the STM-1 link
The following sections describe these tool sets in detail.
Loopback test modes for the STM-1 port
The Matrix Switch provides the following diagnostic loopback test modes for the STM-1 port:
•
SDH facility loop (see section
“Facility Loop [sonetFacilityLoop(1)]”
•
SDH terminal loop (see section
“Terminal loop [sonetTerminalLoop(2)]”
•
H.110 loop (see section
“Other Loop [sonetOtherLoop(3)]”
The facility and terminal loops are specified by the SDH protocol. The H.110 loop is proprietary to the Fore-
Front Matrix Switch, and fulfills the SDH specification for a third vendor-defined loop.
Off
There is NO Ethernet frame activity on either of the 10/100/1000
Ethernet ports. No action recommended
READY
Front
panel
Blue
On
Indicates module is ready for removal from cPCI chassis.
Off
Indicates module NOT ready for removal from cPCI chassis.
Do not remove card from chassis.
ALARM
Rear
blade
Yellow On solid A minor alarm condition has been detected.
Flashing A major alarm condition has been detected.
Off
The Model 6511RC is operating normally. No action recommended.
READY
Rear
blade
Blue
On
Card ready for removal from cPCI chassis.
Off
Card not ready for removal from cPCI chassis.
Do not remove card from chassis.
ON LINE
On
Reserved for future use
Off
Reserved for future use
10/100
ENET
Front
Panel
Green On
Ethernet Link is established
Integrated
LEDs on RJ-
45 connec-
tor
Off
No Ethernet link is established
Yellow On
Flashes to indicates Ethernet frame activity on this port
Off
Indicates no Ethernet frame activity on this port
READY
Blue
On
Card ready for removal from cPCI chassis.
Off
Card not ready for removal from cPCI chassis.
a. This LED provides status indications for the STM-1 WAN link established via the optical or electrical ports on
the Rear Module of the 6511RC
Table 6. LED status indications and recommended actions (Continued)
LED
Location
Color
Status
Meaning
