Hardware overview
27
Model 6511RC User Manual
1 • Introduction
Temperature
Operating range: 32–104°F (0–40°C)
Altitude
Maximum operating altitude: 15,000 feet (4,752 meters)
Humidity
5 to 95% relative humidity (RH), non-condensing
Physical dimensions
•
1.75 inches (4.44 cm) height, standard 19-inch (48.26 cm) width, 12-inch (30.48 cm) depth
•
Weight: 1.55 lbs (0.70 kg)
LED Indicators
LED indicators on the front panel (see
on page 17) and rear panel (see
on page 18) display the
status of Matrix Switch system resources. The front-panel LEDs are described in
. The rear-panel LEDs
are described in
Table 3. Front-panel LED indicators
LED
Color Status
Meaning
POWER
Green On solid Power is being applied.
Flashing The 6511RC has detected a power failure on a power bus.
Off
No input power is being applied.
CPU FAIL
Red
On solid CPU is unable to load the software from FLASH to RAM for operation.
Off
The CPU is operating normally.
ALARM
Yellow On solid A minor alarm condition has been detected.
Flashing A major alarm condition has been detected.
Off
The Model 6511RC system is operating normally.
SYSTEM
Green
Flashing The Model 6511RC system is operating normally.
Off
The Model 6511RCsystem is not functioning properly.
ENET(NODE)
Green On solid Indicates there is Ethernet frame activity on one or more of the 6511RC’s Ethernet inter-
faces, including the two rear-panel 10/100/1000 ports, the front -panel 10/100 port,
and the packet--switched PICMG 2.16 bus.
Off
Indicates NO Ethernet frame activity detected on any of the 6511RC’s Ethernet interfaces,
including the PICMG 2.16 bus.
CLK SOURCE
Green On solid The 6511RC is defined as the Primary (master) clock source for the H.100 bus
Flashing The 6511RC is defined as the Secondary (alternate master) clock source.
Off
The 6511RC is defined as a slave, deriving its clock from the H.110 Bus.
CLK ERROR
Yellow On solid Primary Master Clock source has been lost and the 6511RC is using the secondary
source for its clock.
Flashing Master Clock source and the Secondary Clock source have been lost and the 6511RC
is using its internal crystal for its clock.
Off
No clock errors currently detected.
