9
Sim
ple S
etu
p
Cab
le connections
RQ
TX00
99
Turn off all equipment before connection and read the appropriate operating instructions.
Do not connect the AC mains lead until all other connections are complete.
(Continued on next page)
1
Speaker connections
step 3
Cable connections
L R
CENTER SUBWOOFER FRONT
6 5 2 1 4 3
L R L R SURROUND
SPEAKERS
1
Main unit
[PT865]
Wireless system
L R
Rch
SURROUND
4
Lch
SURROUND
3
CENTER SUBWOOFER FRONT
6 5 2 1
L R
CENTER SUBWOOFER FRONT
6 5 2 1 4 3
L R L R
SURROUND
Lch
FRONT
1
1
3
2
Connecting the speakers to the main unit:
Connect to terminals of the same colour.
Speaker Terminal/connector colour
1 FRONT (L) White
2 FRONT (R) Red
3 SURROUND (L) [PT565] [PT560] Blue
4 SURROUND (R) [PT565] [PT560] Grey
5 CENTER Green
6 SUBWOOFER Purple
Insert the wire fully.
i: White
j: Blue
Push!
e.g. [PT565]
Surround speaker (L)
Speaker cable sticker (included)
Attach the speaker-cable stickers to
make connection easier.
≥ Be careful not to cross (short
circuit) or reverse the polarity of the
speaker wires as doing so may
damage the speakers. DO
NOT
[PT565] [PT560]
Main unit
Insert fully.
Wireless system
[PT865]
Connecting the speakers to the wireless system:
Insert fully.
Insert the wire fully.
i: White
j: Blue
Push!
≥ Be careful not to cross (short
circuit) or reverse the polarity of the
speaker wires as doing so may
damage the speakers. DO
NOT
Main unit e.g. Surround speaker (R)
Insert the wires,
taking care not
to insert beyond
the wire
insulation.
e.g. Front speaker (L)
