Panasonic SC-PT565 - Manual (Page 17)

17
Con
tr
o
l ref
e
rence
g
u
id
e
/
Uti
lisin
g the
ST
AR
T men
u
17
RQ
TX00
99
You can select desired source or access playback/menus by using the
START menu.
When “Input Selection” is selected
You can select a desired source from the menu.
≥ DVD/CD (
➜ 14), FM (➜ 15), [Australia[and[N.Z.] AM (➜ 15),
AUX § ( ➜ 34), DIGITAL IN § ( ➜ 34), USB (➜ 34), iPod (➜ 35)
§ “(TV)” will appear beside “AUX” or “DIGITAL IN”, indicating the TV audio
setting for VIERA Link “HDAVI Control” (
➜ 30).
Press [ 3, 4], then press [OK] to make the settings.
When a disc is loaded or an USB device is connected, you can also
access playback or menus from the START menu.
e.g.
[DVD-V]
When the on-screen control panel appears
e.g.
[DVD-V] (when “Playback Disc” is selected from the START menu)
You can operate the playback with the indicated controls.
VOLUME
14 15 16 17
SW BOOS T
OPEN CLO SE
9
- +
SELECTOR TUNE
MEMORY TUNE MODE FM MODE
AC IN
SW
BOOST
1 2 3 4 5 6 7 8
OPEN CLOSE
MIC VOL
SETUP MIC
12 11 13 10 Southeast Asia, Thailand, The Middle East,
South Africa, Saudi Arabia and Kuwait
1 Standby/on switch [ Í/I]
Press to switch the unit from on to standby mode or vice
versa. In standby mode, the unit is still consuming a small
amount of power. (
➜ 18)
2 This indicator lights when the unit is connected to the AC
mains supply.
3 Open/Close the disc tray ( ➜ 18)
4 Turn Subwoofer Boost on/off ( ➜ 33)
5 Select the source
DVD/CD #USB#FM#AUX#D-IN#IPOD
^----------------------------------------------------------------}
[Australia[and[N.Z.]
DVD/CD
#USB#FM#AM#AUX#D-IN#IPOD
^-------------------------------------------------------------------------}
6 Skip or slow-search play / Select the radio stations
( ➜ 15, 18)
7 Stop playing / Select the tuning mode / Adjust the FM
reception condition ( ➜ 15, 18)
8 Play discs / Memorize the receiving radio stations
( ➜ 18, 28)
9 Connect iPod ( ➜ 35)
: Connect microphones § ( ➜ 29)
; Connect USB device ( ➜ 34)
< [PT865] Connect Auto speaker setup microphone ( ➜ 33)
= Adjust microphone volume § ( ➜ 29)
> Remote control signal sensor
? Display
@ Adjust the volume of the main unit
A Connect headphones (not included)
Headphone plug type: ‰3.5 mm stereo mini plug
≥ Reduce the volume before connecting.
≥ Audio is automatically switched to 2-channel stereo.
≥ To prevent hearing damage, avoid listening for prolonged periods
of time.
Excessive sound pressure from earphones and headphones can
cause hearing loss.
Utilising the START menu
1 Show the START menu.
e.g.
2 Select an item.
≥ To exit press [START].
START
DVD/CD Home Cinema
OK
RETURN
Input Selection
OK
DVD/CD Home Cinema
OK
RETURN
Input Selection
Playback Disc
TOP MENU (DVD)
MENU (DVD)
Playback/
menu access
SEARCH
RETURN
SEARCH
PLAY
PAUSE
STOP
