Operating other equipment
You can play an external source through your home theater system.
Preparation
Confirm the audio connection to the AUX terminal on the main unit
(
➜ 10).
≥ Reduce the volume on the TV to its minimum, and then adjust the
volume of the main unit.
≥ You can enjoy surround sound effect when you press [ÎPLII] to turn
on Dolby Pro Logic II ( ➜ 32).
Preparation
Confirm the audio connection to the OPTICAL IN terminal on the main
unit (
➜ 11).
Select to suit the type of audio from the OPTICAL IN terminal on the main
unit.
1
While in “D-IN” mode
Press [SETUP] to select “MAIN/SAP”, “DRC” or “PCM FIX”.
2 While the selected mode is displayed
Press [
3, 4] to make the setting.
MAIN/SAP mode (Only works with Dolby Dual Mono)
MAIN, SAP
§ , MAIN+SAP § (stereo audio)
§ “SAP” = Secondary Audio Program
Dynamic Range Compression
DRC ON: Adjust for clarity even when the volume is low by compressing
the range of the lowest sound level and the highest sound level.
Convenient for late night viewing. (Only works with Dolby
Digital)
DRC OFF
PCM FIX mode
PCM ON: Select when receiving only PCM signals.
PCM OFF: Select when receiving Dolby Digital and PCM signals.
[Note]
Audio that is input through the OPTICAL IN terminal cannot be output
through the HDMI terminal.
You can connect and play tracks or files from USB mass storage class
devices.
Devices which are defined as USB mass storage class:
– USB devices that support bulk only transfer.
– USB devices that support USB 2.0 full speed.
Preparation
≥ Before connecting any USB mass storage device to the unit, ensure that
the data stored therein has been backed up.
≥ It is not recommended to use a USB extension cable. The USB device
connected using the cable will not recognised by this unit.
Connect the USB device (not included).
e.g. [PT565]
Play starts from the selected content.
≥ You can enjoy surround sound effect when you press [ÎPLII] to turn
on Dolby Pro Logic II ( ➜ 32).
≥ For other operating functions, they are similar to those described in
“Playing Discs” ( ➜ 18 to 28).
Supported Formats
§ For Panasonic D-Snap/DIGA
[Note]
≥ Maximum: 256 folders, 4000 files, 12 characters for file/folder name
≥ Only one memory card will be selected when connecting a multiport
USB card reader. Typically the first memory card inserted.
≥ When connecting the USB mass storage device, ensure the iPod has
been disconnected.
Enjoying TV audio
Select “AUX”.
Enjoying digital audio
Select “D-IN” (Digital In).
Making settings for digital audio input
-SLEEP -REPEAT
-FL DISPLAY -PLAY MODE
MUTING SUBWOOFER
-CH SELECT
SETUP SOUND
TOP MENU
MENU
DIRECT
NAVIGATOR
START
PLAY
LIST
SLOW/SEARCH
PLAY PAUSE STOP
SKIP
1 2 3
4 5 6
7 8 9
0 10
CANCEL
VOL
ONE TOUCH PLAY
FM/EXT-IN
TV/AV VOL iPod/USB
DVD
-W.S.
PL
TV
LEVEL
OK
-RETURN
-KARAOKE
-ECHO
-FUNCTIONS
SETUP
PLII
,
STOP, PAUSE PLAY
-RETURN
iPod/USB
OK
— REPEAT
-PLAY MODE
Australia and N.Z.
RETURN
FUNCTIONS
Australia and N.Z.
FM/AM/
EXT-IN
Australia and N.Z.
-FUNCTIONS
FM/EXT-IN
FM/EXT-IN
FM/AM/
EXT-IN
[Australia]
[and[N.Z.]
FM/EXT-IN
FM/AM/
EXT-IN
[Australia]
[and[N.Z.]
Playing from an USB device
1 Select “USB”.
The menu screen appears.
e.g.
≥ If “PLAYBACK MENU” screen appears,
select “AUDIO/PICTURE” or “VIDEO” by
pressing [
3, 4] and then [OK].
2 Select an item.
≥ To return to the previous screen, press
[-RETURN]. ( [Australia[and[N.Z.]: [RETURN])
Still pictures JPEG (Extension: “.jpg”, “.JPG”, “.jpeg”, “.JPEG”)
Music MP3 (Extension: “.mp3”, “.MP3”)
WMA (Extension: “.wma”, “.WMA”)
Video MPEG4 § (Extension: “.asf”, “.ASF”)
SW BOOS T
OPEN CLO SE
- +
USB device
Main unit
iPod/USB
USB
ROOT
OK
Songs
Concer t_01
Concer t_02
Southern AI
RETURN
OK
