● Motion Detector (MOTION DET)
1. Display SET UP MENU on the monitor screen by referring to page
16.
2. Move the cursor to MOTION DET and select ON or OFF by using
the joystick.
The factory default setting is OFF.
3. If ON is selected, press the CAM (SET) key.
The MOTION DETECT menu appears.
You can mask the areas in this menu.
4. Move the cursor to MASK SET and press the CAM (SET) key.
48 mask areas appear on the monitor screen.
Refer to the Light Control Setting on page 37 for masking opera-
tions.
5. After masking areas, press the MON (ESC) key. The MOTION
DETECT menu appears on the monitor screen.
6. Move the cursor to ALARM and select ON or OFF by using the
joystick.
The factory default setting is OFF.
ON: The alarm signal is supplied while the display mode is acti-
vated.
OFF: The alarm signal is not supplied while the display mode is
activated.
7. Move the cursor to DISPLAY MODE.
Press the CAM (SET) key to see the present setting. The areas
that detect the motions blink.
8. Move the cursor to LEVEL by using the joystick.
Obtain the optimum detection level by moving the joystick to the
right or left.
Note: Repeat the above procedures until you obtain the adjusted
results.
9. Move the cursor to RECOVER TIME by using the joystick.
The factory default setting is 1 MIN.
You can select the following recover times.
10. Move the cursor to RET and press the CAM (SET) key to return to
SET UP.
** MOTION DETECT **
LEVEL
DISPLAY MODE
ALARM
MASK SET
RECOVER TIME
RET
••••|••••
- +
OFF
1MIN
Motion detect menu
OFF 1MIN 2MIN 3MIN 5MIN
60MIN 30MIN 20MIN 10MIN
** SET UP **
CAMERA ID
ALC/MANUAL
SHUTTER
AGC
SENS UP
SYNC
WHITE BAL
MOTION DET
AF MODE
RET SPECIAL2
OFF
ALC
OFF
ON(MID)
X2 AUTO
INT
ATW1
ON
MANUAL S
Camera setting menu
