Synchronization (SYNC)

1. Display SET UP MENU on the monitor screen by referring to page

16.

2. Move the cursor to SYNC and select LL or INT by using the joy-

stick.
The factory default setting is INT.

Important Notices:

1. The priority of SYNC modes is as follows:

1. Multiplexed vertical drive (VD2) (highest priority)
2. Line-lock (LL)
3. Internal sync (INT) (lowest priority)

2. To use internal sync, select INT.
3. Whenever the vertical drive pulse (VD2) is supplied to the cam-

era, the camera sync mode is automatically switched to the multi-
plexed vertical drive pulse (VD2) regardless of the selected sync
mode.

Line-lock Sync Mode (LL)

1. Display SET UP MENU on the monitor screen by referring to page

16.

2. Move the cursor to SYNC and select LL by using the joystick. LL

sync mode is not available when the multiplexed vertical drive
(VD2) pulse is supplied.

3. After selecting LL, press the CAM (SET) key.

The SYNC menu appears on the monitor screen.

4. Supply the video output signal of the camera to be adjusted and

the reference video output signal (for example, Camera 1) to a
dual-trace oscilloscope.

5. Set the dual-trace oscilloscope to the vertical rate and expand the

vertical sync portion on the oscilloscope.

6. Move the cursor to COARSE by using the joystick.

7. Match the vertical phases for both video output signals as closely

as possible by using the joystick. The coarse adjustment can be
incremented in steps of 22.5 degrees (16 steps) with the joystick.

Note:

After the 16th step, the adjustment returns to the first step.

** SET UP **
CAMERA ID
ALC/MANUAL
SHUTTER
AGC
SENS UP
SYNC
WHITE BAL
MOTION DET
AF MODE

RET SPECIAL2

OFF
ALC
OFF
ON(MID)
X2 AUTO
INT
ATW1
OFF
MANUAL S

Camera setting menu

** SET UP **
CAMERA ID
ALC/MANUAL
SHUTTER
AGC
SENS UP
SYNC
WHITE BAL
MOTION DET
AF MODE

RET SPECIAL2

OFF
ALC
OFF
ON(MID)
X2 AUTO
LL
ATW1
OFF
MANUAL S

Camera setting menu

** SYNC **

V PHASE

COARSE

FINE

RET

1(1--16)

•|•••••••
- +

SYNC menu

1 (1 - - - 16): 0 degrees
2 (1 - - - 16): 22.5 degrees

16 (1 - - - 16): 337.5 degrees
