Page 62
Ref.
No.
Part No.
Part Name &
Description
Pcs
Remarks
C8422,2
3
F1G1C104A083
16V 0.1U
2
F1G1C104A042
C8425
F2G0J330A083
6.3V 33U
1
C8426
F1G1C104A083
16V 0.1U
1
F1G1C104A042
C8501
ECJ3YB1A106K
10V 10U
1
C8502-
04
F1G1C104A083
16V 0.1U
3
F1G1C104A042
C8505
ECJ0EC1H221J
50V 220P
1
C8506
ECJ0EC1H101J
50V 100P
1
C8550
F2G0J330A031
6.3V 33U
1
C8551
F1G1C104A083
16V 0.1U
1
F1G1C104A042
C8552
F2G1C100A072
16V 10U
1
C8553
F2G0J470A031
6.3V 47U
1
C8554
ECJ1VB0J105K
6.3V 1U
1
C8561
F1G1C104A083
16V 0.1U
1
F1G1C104A042
C8562
F2G1C100A072
16V 10U
1
C8563
F2G0J470A031
6.3V 47U
1
C8564
ECJ1VB0J105K
6.3V 1U
1
C8601
F1G1C104A083
16V 0.1U
1
F1G1C104A042
C8611
F1G1C104A083
16V 0.1U
1
F1G1C104A042
C8621
ECJ0EC1H150J
50V 15P
1
C8622
ECJ0EC1H220J
50V 22P
1
C8651,5
2
F1G1C104A083
16V 0.1U
2
F1G1C104A042
D1011
B0EDKT000009
DIODE
1
D1031
AP01C
DIODE
1
B0HADV000010
D1041
B0HAGM000006
DIODE
1
D1045
MA4200L
DIODE
1
MAZ42000LF
D1046
MA4240H
DIODE
1
MAZ42400H
D1051
MA4068M
DIODE
1
MAZ40680M
D1071
MA4100M
DIODE
1
MAZ41000MF
D1072
MA2C16500E
DIODE
1
D1081
MA2C18500E
DIODE
1
D1082
MA2C16500E
DIODE
1
D1083
MA4100H
DIODE
1
MAZ41000H
D1084
MA4160-L
DIODE
1
MAZ41600L
D1111
21DQ06FC4
DIODE
1
B0JAMG000013
D1121
21DQ06FC4
DIODE
1
B0JAMG000013
D1125
MA2J11100L
DIODE
1
D1141
B0JAML000011
DIODE
1
D1151,5
2
B0JAML000011
DIODE
2
D1153
B0EAKM000122
DIODE
1
D1171
B0JAME000037
DIODE
1
D4301
MA4056H
DIODE
1
MAZ40560H
D6081
MA4091L
DIODE
1
MAZ40910L
D6101
B3AAA0000721
DIODE
1
D8231
MA2J11100L
DIODE
1
D8550
MA2J11100L
DIODE
1
D8571
MA2J72800L
DIODE
1
DP6081
A2BA00000217
DISPLAY TUBE
1
F1001
K5D162BLA013
FUSE
1
FP2001
K1MN07A00005
CONNECTOR(7P)
1
FP2601
K1MN07B00082
CONNECTOR(7P)
1
FP3501
K1KA14A00135
CONNECTOR(MALE)
14P
1
FP3502
K1KA20A00215
CONNECTOR(MALE)
20P
1
FP6101
K1MN06C00005
CONNECTOR(6P)
1
FP6102
K1MN06A00013
CONNECTOR(6P)
1
FP6103
K1KA02AA0193
CONNECTOR(2P)
1
FP6154
VJS3623A005W
CONNECTOR(FEMALE)
5P
1
K1MN05A00003
FP8101
K1KB20A00165
CONNECTOR(20P)
1
FP8102
K1KB14A00074
CONNECTOR(14P)
1
FP8201
RJS2A5106T
CONNECTOR(FEMALE)
6P
1
K1MN06A00022
FP8501
K1MN26A00061
CONNECTOR(26P)
1
IC1021
C0DACZH00024
IC
1
IC1101
C0DAEMB00003
IC
1
Ref.
No.
Part No.
Part Name &
Description
Pcs
Remarks
IC1151
C0DBZHG00047
IC
1
IC1195
C0DBFGC00008
IC
1
IC3501
C9ZB00000498
IC
1
IC4301
C0ABBB000118
IC
1
IC4671
C0ABBB000216
IC
1
C0ABBB000126
IC4691
C0ABBB000216
IC
1
C0ABBB000126
IC6001
MN101C87AAE
IC
1
IC8001
RFKVDS39BKIT
IC
1
IC8051
C3ABPG000133
IC
1
IC8111
C0CBCBD00018
IC
1
IC8251
C0GBG0000054
IC
1
IC8421
C0FBBK000047
IC
1
IC8601
C0EBE0000384
IC
1
IC8651
RFKWSK82C160
IC
1
IP1171
B1ZAZ0000030
IC PROTECTOR
1
IR6131
B3RAD0000070
REMOTE CONTROL
SENSOR
1
J4671,7
2
K2HB102J0038
JACK, MIC2
2
JK4401
K2YZ19000001
JACK, AUDIO VIDEO
OUT
1
K8101-
03
ERJ3GEY0R00
1/10W 0
3
K8104
ERJ6GEY0R00V
1/8W 0
1
K8105
ERJ3GEY0R00
1/10W 0
1
K8421
ERJ3GEY0R00
1/10W 0
1
K8651
ERJ2GE0R00X
1/16W 0
1
L1001
ELF15N003A
NOISE FILTER
1
L1111
G0A100HA0023
COIL 10UH
1
L1117
G0C100JA0048
COIL 10UH
1
L1131
G0C330KA0065
COIL 33UH
1
L1141
G0C330KA0065
COIL 33UH
1
L1151
G0A220GA0026
COIL 22UH
1
L3501
G0C220JA0019
COIL 22UH
1
L3801
VLQ0599J680
COIL 68UH
1
G0C680JA0026
L4291
G0C391JA0064
COIL 390UH
1
L6001
G0C101JA0019
COIL 100UH
1
L8201
G1C100K00020
COIL 10UH
1
L8202
J0JCC0000079
COIL 9UH
1
L8301
G1C100KA0055
COIL 10UH
1
L8302
J0JCC0000079
COIL 9UH
1
L8550
G1C100KA0055
COIL 10UH
1
LB3531-
33
J0JBC0000117
COIL
3
LB3534
J0JCC0000186
COIL
1
LB3535,
36
J0JBC0000117
COIL
2
LB4601
J0JCC0000120
COIL
1
LB4671
J0JCC0000120
COIL
1
LB4673,
74
J0JCC0000120
COIL
2
LB8001,
02
J0JHC0000097
COIL
2
LB8003,
04
ERJ2GE0R00X
1/16W 0
2
LB8005,
06
ERJ3GEY0R00
1/10W 0
2
LB8301-
05
J0JCC0000371
COIL
5
LB8401
ERJ2GEJ151
1/16W 150
1
LB8421-
24
ERJ2GE0R00X
1/16W 0
4
LB8491
ERJ2GE0R00X
1/16W 0
1
LB8502
J0JHC0000097
COIL
1
LB8503
ERJ2GE0R00X
1/16W 0
1
LB8504,
05
J0JCC0000371
COIL
2
LB8507
J0JCC0000371
COIL
1
62
DVD-K29GCS
