DVD-K29GCS
VIDEO BLOCK DIAGRAM DVD-K29GCS
VIDEO BLOCK DIAGRAM
E
D
C
A
B
1.2Vp-p(20usec./div.)
IC3501-12
1.2Vp-p(20usec./div.)
IC3501-11
JK4401
PR
PB
Y
VIDEO OUT
JK4401
S-VIDEO OUT
JK4401
IC3501
(VIDEO DRIVE)
VIDEO MAIN SIGNAL
11
12
13
14
15
16
CROUT
CBOUT
CYOUT
YOUT
OUT
CVBS
COUT
-6dB
1.4V
MUTE
DRIVER
75
DRIVER
75
DRIVER
75
DRIVER 75
DRIVER 75
DRIVER
75 CRIN
9
8
6
4
2
CBIN
CYIN
YIN
CIN
6.75MHz
6.75MHz
13.5MHz
6.75MHz
6.75MHz
BIAS
MUTE
4dB
BIAS
2dB LPF
LPF 2dB
2dB LPF
LPF
LPF
+
2dB
8dB
2dB
BIAS
4dB
4dB
CLAMP
CLAMP
4dB
4dB
BIAS
2.0Vp-p(20usec./div.)
IC3501-13,14
2.0Vp-p(20usec./div.)
IC3501-15
1.5Vp-p(20usec./div.)
IC3501-16
