13
Configure DIP switch S2
Switches S2-1 through S2-8 are for configuring Local/Remote Loop, RDL
response, and front panel switch operation (see Table 2). Descriptions of
the switch options follow the table.
Switch S2-1: Local/Remote Loop. Switch S2-1 determines which Loop
can be activated from the front panel loop switches (P1 to P4)
Switch S2-7: Response to RDL. Switch S2-7 enables or disables the
ability of the model 1194 to respond to RDL (Fiber Loop)
Switch S2-8: Front Panel Switches. Switch S2-8 enables or disables
front panel switches, affecting the operation of P1 to P4 (loop switches)
and test pattern switches. In the ON position, S2-8 disables the operation
of front panel switches preventing the accidental activation of diagnostic
loops and test patterns.
Table 2: Switch S2 summary
Position Function Default Setting Selected Option
S2-1 Local/Remote Loop OFF Local Loop
S2-2
S2-3
Reserved S2-4
S2-5
S2-6
S2-7 Response to RDL OFF Enabled
S2-8 Front panel switches OFF Enabled
S2-1 Loop selected
OFF Local Loop
ON Remote Loop
S2-7 RDL Response
ON Disabled (no response)
OFF Enabled
S2-8 Front panel Switches
ON Disabled
OFF Enabled
