Powerware 685 - Manual (Page 49)

A---7
Powerware 9350 Series 685 and 1085 Auxiliary Battery Cabinets
Installation Manual 164201408 Rev. P00 053002
DESCRIPTION:
DRAWING NO:
2 of 2
SHEET:
WALL --- NO BACK ACCESS REQUIRED
BOTTOM VIEW
914.4 (36.00)
MINIMUM CLEARANCE
FOR SUBASSEMBLY
REMOVAL
TOP VIEW
Dimensions are in millimeters (inches)
Series 685 Battery Cabinet
Series 685 Battery Cabinet
Series 685 Battery Cabinet (plan)
164201408--1
201.1
(7.92)
335
(13.19)
120
(4.72)
80
(3.15)
175
(6.89)
282
(11.1)
226.9
(8.93)
280.4
(11.04)
148
(5.83)
75
(2.95)
735.8
(28.97)
613
(24.14)
135
(5.32)
453
(17.83)
300.4
(11.83)
61.4
(2.42)
141.4
(5.57)
802.7
(31.6)
530
(20.87)
690
(27.17)
151
(5.95)
71
(2.80)
TOP CABLE ENTRY LOCATION
(COVER SECURED WITH SCREWS)
BOTTOM CABLE ENTRY LOCATION
(COVER SECURED WITH SCREWS)
