Powerware 9350 Series 685 and 1085 Auxiliary Battery Cabinets
Installation Manual 164201408 Rev. P00 053002
Connecting to Powerware 9350 30---160
The method you use to install your battery cabinets depends on which
UPS you have. For the purpose of discussion, this chapter uses the term UPS
to refer to the UPS cabinet, and the term battery cabinet to refer to any battery
cabinet. There are two different sizes of battery cabinets, but the procedure for
connecting the cabinets to your UPS system is the same.
• Joining one or more battery cabinets to the UPS
• One or more battery cabinets separately located from the UPS.
The Powerware 9350 UPS with Integral Battery Cabinets
Use this procedure to attach a Powerware 9350 Series 685 or Series 1085 Battery
Cabinet to any Powerware 9350 UPS cabinet (see Figure 6).
Figure 6. UPS with Integral Battery Cabinet
