27
Powerware 9350 Series 685 and 1085 Auxiliary Battery Cabinets
Installation Manual 164201408 Rev. P00 053002
Completing the Installation Checklist
The final step in installing your battery cabinet is to complete the Installation
Checklist. This checklist ensures that you have installed all hardware, cables,
and other equipment. Completing all items on the checklist will ensure a smooth
installation. Make a copy of the Installation Checklist before filling it out, and retain
the original.
After completing your installation, a service representative will be able to verify the
operation of your battery cabinet, and commission it to support your critical load.
The service representative cannot perform any installation tasks other than verifying
that the battery cabinet has been correctly installed. Service personnel may request
a copy of the completed Installation Checklist to be sure you have completed all
applicable equipment installation requirements.
NOTE:
The Installation Checklist MUST be completed prior to starting up the UPS system
for the first time.
Installation Checklist for Powerware 9350 30 through 160
- All packing materials and restraints have been removed from each cabinet.
- Each cabinet in the battery system is placed in its correct location.
- All cabinets are bolted together.
- A ground wire is installed between all cabinets that are bolted together.
- All conduits and cables are properly routed to the battery cabinets.
- A ground conductor is properly installed.
- Battery cables and harness are terminated on the K2 battery contactor E4 and E5 in
the UPS cabinet.
- Internal battery cabinet connections have been completed (bus bars, plugs, etc.)
- Air conditioning equipment is installed and operating correctly.
- The area around the installed battery system is clean and dust-free.
(It is recommended that the battery cabinet be installed on a sealed concrete pad or a
sealed concrete floor.)
- Adequate working area exists around the battery cabinet and other cabinets.
- Adequate lighting is provided around all battery cabinet equipment.
- A remote battery disconnect control is mounted in its installed location and its wiring is
terminated inside the battery cabinet (OPTIONAL).
