36
3. Setup
3-6. Adjusting the output signal phase
The phase of the output video signals can be adjusted.
1 Press the [FUNC] switch to light its indicator, and then press the [SETUP] switch to display the SETUP
menu.
2 Turn [F1] to display the OUPHS menu.
3 Turn [F], and select 0H or 1H using the SYS item.
0H: The output video signals are output to the system REF signal with using in-phase.
The frame synchronizer function is ON for all input signals.
1H: The output video signals are output to the system REF signal with 1H delay.
4 Turn [F3] to adjust H phase using the HPHS item, and turn [F4] to adjust V phase using the VPHS item.
HPHS can be adjusted within a range of –0.5H to +0.5H and VPHS within a range of –100H to +100H.
)
061)4 4:4
)
)1)4 71)4
Output video signal phase adjustment
Phase Video format Adjustment range
HPHASE 1080i/59i −1100 to 1099
1080/50i −130 to 1319
70/59p −85 to 84
70/50p −990 to 989
480/59i −49 to 48
576/50i −43 to 431
VPHASE Same for all formats −100 to 100
