MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS
■
Front View
q
Power switch [POWER]
Toggles the power on and off.
w
Power indicator
Lights up when the power switch is set to ON.
e
Mono input level knobs [MONO 1 to 4]
Monaural input levels are adjustable with these knobs
corresponding widely to the connected devices, e.g.,
from microphones up to line-level source devices.
Input gains are in conjunction with output gains. (Dual-
level control)
Note:
When using Panasonic wireless microphones, set
the output level to –20 dB.
r
Stereo input level knobs [STEREO 1 to 4]
Stereo input levels are adjustable with these knobs cor-
responding widely to the connected devices, e.g., from
microphones up to line-level source devices.
t
Stereo output assign button [ST]
Assigns the signal inputs of the MULTI INPUT ST jack,
MULTI INPUT MONO connector, and LINE IN to
STEREO OUT jacks.
ON (
;
):
These inputs are assigned to the STEREO
OUTPUT jack.
OFF(
l
):
These inputs are not assigned to the STEREO
OUTPUT jack.
y
Monaural output assign button [MONO]
Assigns the signal inputs of the MULTI INPUT ST jack,
the MULTI INPUT MONO connector, and the LINE IN
jack to MONO OUTPUT jack.
ON (
;
):
These inputs are assigned to MONO OUTPUT
jack.
OFF(
l
):
These inputs are not assigned to MONO
OUTPUT jack.
u
Sub output assign button [SUB]
Assigns the signal inputs of the MULTI IN STEREO
jacks, the MULTI INPUT MONO connector, and the
LINE IN jack to SUB OUTPUT jack.
ON (
;
):
These inputs are assigned to SUB OUT-
PUT jack.
OFF (
l
):
These inputs are not assigned to SUB
OUTPUT jack.
i
Multiple input level knob [MULTI IN]
Multiple input level is adjustable corresponding widely
to the connected device.
o
Line input jack [LINE IN]
Connects to an input device such as a CD player, MD
player or tape recorder.
Stereo/mono: 1 circuit
Output jack: Stereo mini jack
Input level: –10 dB
Impedance: 10 k
Ω
, unbalanced
4
2
8
10
0
1
6
4
2
8
10
0
2
6
4
2
8
10
0
3
6
4
2
8
10
0
4
6
MONO
POWER
4
2
8
10
0
1
6
4
2
8
10
0
2
6
4
2
8
10
0
3
6
4
2
8
10
0
4
6
4
4
2
2
8
8
10
0
10
0
6
6
ST
MULTI IN
4
2
8
10
0
6
SUB OUT
STEREO
MONO
STEREO OUT
INPUT
REAK
LINE IN
SUB
4
2
8
10
0
6
MONO OUT
Audio Mixer WR-XS3
w
Power indicator
q
Power switch
e
Mono input level knobs
r
Stereo input level knobs
t
i
Multiple input level knob
o
Line input jack
u
!1
Output level knobs
y !0
Input peak indicator
Multiple input / line input assign buttons
4
2
8
10
0
6
Wireless
maicrophone
Microphone
Other input
devices
HA
HPF
MONO IN
–80 to –10dB
