Chapter 3
Removing the Card Reader Board
1. See “Removing the Upper Cover” on page 62.
2. Unlock the mainboard to card reader cable connector.
3. Remove the cable from the chassis by pulling up on the adhesive.
4. Remove one (1) screw from the card reader board.
Step
Size
Quantity
Screw Type
Card Reader
M2*3
1
