USB/B Board
Power Board
ITEM
DESCRIPTION
JUSB1/JUSB2
USB Connector
ITEM
DESCRIPTION
ITEM
DESCRIPTION
LED1
For NEW70 ON/OFF LED
LED9
For NEW50 WWAN LED
LED2
For NEW80 ON/OFF LED
LED10
For NEW70 WLAN LED
LED3
For NEW90 ON/OFF LED
LED11
For NEW50 POWER LED
LED4
For NEW70 MEDIA LED
LED12
For NEW50/NEW90 WLAN LED
LED5
For NEW80 MEDIA LED
SW1
For NEW70 Power BTN
LED6
For NEW50/NEW90 MEDIA LED
SW2
For NEW80 Power BTN
LED7
For NEW70 WWAN LED
SW3
For NEW90 Power BTN
LED8
For NEW80 WLAN LED
