background image

Sync Serial port

63

SmartNode 4900 User Manual

C • Port pin-outs

Sync Serial port

Two types of serial ports are available: V.35 or X.21. They are configured as DTE. The V.35 is presented on a
DB-25 female connector (see

table 14

for pin-outs). The X.21 is presented on a DB-15 female connector (see

table 15

for pin-outs).

Note

Pins not listed are not used

Table 14. V.35 serial port signals (DB-25 connector)

Pin

Description

1

Frame Ground

2

TD-a (to DCE)

3

RD-a (from DCE)

4

RTS (to DCE)

5

CTS (from DCE)

6

DSR (from DCE)

7

Signal Ground

8

CD (from DCE)

9

RC-b (from DCE)

11

XTC-b (to DCE)

12

TC-b (from DCE)

14

TD-b (to DCE)

15

TC-a (from DCE)

16

RD-b (from DCE_

17

RC-a (from DCE)

20

DTR (to DCE)

24

XTC-a (to DCE)

Table 15. X.21 serial port signals (DB-15 connector)

Pin

Description

1

Signal Ground

8

DTE Common Return

2

Transmit (to DCE)

3

Control (to DCE)

4

Receive (from DCE)

5

Indication (from DCE)

6

Signal Element Timing (from DCE)

9

Transmit (to DCE)

10.

Control (to DCE)

11

Receive (from DCE)

12

Indication (from DCE)

13

Signal Element Timing (from DCE)
