SmartNode 4900 Series detailed description 19
SmartNode 4900 User Manual 1 • General information
SmartNode 4900 Series rear panels
The SmartNode 4900 rear panel ports are shown in figure 3 and described in table 3 on page 20.
Figure 3. SmartNode 4900 rear panels
