Management 59
SmartNode 4900 User Manual B • Specifications
802.1p VLAN tagging
IPSEC AH & ESP Modes
Manual Key; IKE optional
AES/DES/3DES Encryption
Management
Industry standard CLI with local console (RJ-45, RS-232) and remote Telnet access
TFTP configuration & firmware loading
SNMP v1 agent (MIB II and private MIB)
Built-in diagnostic tools (trace, debug)
Operating environment
Temperature
Operating range: 32–104°F (0–40°C)
Internal temperature: Available in real-time on the IpChannel Bank web pages
Humidity
5 to 90% relative humidity (RH), non-condensing
Altitude
Maximum operating altitude: 15,000 feet (4,752 meters)
System
• The processor is a Motorola MPC875 series 32-bit PowerPC core, 133 MHz
• 8 MB Flash
• 32 MB SDRAM
Dimensions
1.75 inches (4.44 cm) height, standard 19-inch (48.26 cm) width, 12 inches (30.48 cm) depth
Weight and power dissipation
See table 12 .
Table 12. SmartNode weight and maximum power specifications
SmartNode model Weight Maximum power dissipation
IpChannel Bank 4912 9.1 lb (4.1 kg) 25W
IpChannel Bank 4916 9.1 lb (4.1 kg) 30W
IpChannel Bank 4924 9.1 lb (4.1 kg) 40W
