Panasonic SC-RT50 - Manual (Page 34)

34
RQT8655
The radio
Preparation
pTurn off TV while using radio since noise may occur.
pPress [THEATER] to switch the remote control to operate this unit.
1
Press [FM/AM] to select the “FM” or “AM”.
2
Press [ ] or [] to select the
frequency of the required station.
TUNED: Displayed when a radio
station is tuned.
ST: Displayed when a stereo FM
broadcast is being received.
Press and hold [ ] or [] until the frequency starts scrolling
to start automatic tuning. Tuning stops when a station is found.
3
Adjust the volume with [ A B VOLUME].
w If noise is excessive
Press [FM MODE].
Each time you press the button:
FM: Changes between stereo and forced monaural.
AM: BP1
BP2 BP3 BP4 (BPNBeat Proof)
$
Select between BP1 and BP4 that receives good reception.
The FM mode is cancelled when you change the frequency.
w FM frequency step
The step is factory-set to 0.2 MHz, but you can change it to receive
broadcasts allocated 0.1-MHz steps.
1 Press [FM/AM] to select “FM”.
2 Press and hold [
w] on the main unit.
After a few seconds the display changes to show the current
minimum frequency. Continue to hold the button down. The
minimum frequency changes and the step is changed.
To return to the original step, repeat the above steps.
[Note]
Any FM/AM frequencies preset in channels will be changed by this
procedure. Preset them again.
Preset channels to make selection simple.
Up to 30 stations can each be set in the FM and AM bands.
1
Press [FM/AM] to select the “FM” or “AM”.
2
Press [ ] or [] to tune to the
lowest frequency.
FM: 87.9 MHz or 87.5 MHz
AM: 520 kHz
3
Press and hold [ENTER].
Release the button when “AUTO FM” or “AUTO AM” is lit on
the display.
The tuner presets all the stations it can receive into the
channels in ascending order.
p“SET OK” is displayed when the stations are set. The last
station to be set is then played.
pThe unit of display is MHz for FM radio and kHz for AM radio when
the selector is in FM/AM mode.
p“ERROR” is displayed
Presetting was unsuccessful. Preset manually.
1
Tune to the station (
➡ left).
2
Press [ENTER].
3
While “MEMO” is flashing on the display
Press the numbered buttons or [ 9 : CH]
to select a channel and press [ENTER].
e.g., “2”: [0] ➡ [2]
“12”: [1] ➡ [2]
The station occupying a channel is erased if another station is preset
in that channel.
1
Press [FM/AM] to select “FM” or “AM”.
2
Press the numbered buttons or
[
9 : CH] to select the channel.
e.g., “2”: [0] ➡ [2]
“12”: [1] ➡ [2]
[Note]
If there is nearby electrical interference during auto tuning the
frequency may come to a halt without locating a channel. Turn off the
power of the nearby electrical equipment.
w Use FM outdoor antenna if radio reception is
poor.
pDisconnect the FM indoor antenna.
pThe antenna should be installed by a competent technician.
[Note]
pDisconnect the outdoor antenna when the unit is not in use.
pDo not use the outdoor antenna during an electrical storm.
Manual tuning
SRD MUSIC
Numbered
buttons
9:CH
THEATER
,
A B VOLUME
■
H.BASS
SRD ENH
SURROUND MUSIC
SFC/EQ
C. FOCUS,
FM MODE
SRD MUSIC
, , ,
ENTER
A B VOLUME
9:CH
FM/AM
Preset tuning
Automatic presetting
Manual presetting
Selecting channels
75 j coaxial cable
(not included)
Antenna plug
(not included)
Back of
the main unit
FM outdoor antenna
(Using a television
antenna)
