Specifications
General
Rated power source ............... 14.4 V DC
(allowable voltage range:
12.0 14.4 V DC)
Grounding system ................... Negative type
Max. current consumption
..................................................... 10.0 A
Dimensions (W × H × D):
Chassis ............................... 178 Ч 100 Ч 160 mm
Nose ..................................... 169 Ч 94 Ч 17 mm
Weight .......................................... 2.5 kg
Audio/DSP
Continuous power output is 22 W per channel minimum
into 4 ohms, both channels driven 50 to 15,000 Hz with
no more than 5% THD.
Maximum power output ....... 50 W × 4
Load impedance ...................... 4 W (4 8 W allowable)
Preout max output level/output impedance
..................................................... 1.8 V/1 kW
Loudness contour ................... +10 dB (100 Hz), +6.5 dB
(10 kHz) (volume: 30 dB)
Equalizer (13-Band Graphic Equalizer):
Frequency .......................... 50/80/125/200/315/500/800
Hz
1.25/2/3.15/5/8/12.5 kHz
Equalization range ........ ±12 dB
Auto equalizer (just for standard mode):
Frequency .......................... 50/80/125/200/315/500/800
Hz
1.25/2/3.15/5/8/12.5 kHz
Equalization range ........ +6 12 dB
Network (standard mode):
HPF (Front/rear):
Frequency ................ 50/63/80/100/125 Hz
Slope .......................... 12 dB/oct
Subwoofer:
Frequency ................ 50/63/80/100/125 Hz
Slope .......................... 18 dB/oct
Gain ............................ +6 24 dB
Phase ........................ Normal/Reverse
Network (3-way network mode):
High HPF:
Frequency ................ 1.6/2/2.5/3.15/4/5/6.3/8/10/
12.5/16 kHz
Slope .......................... 6/12 dB/oct
Gain ............................ 0 24 dB/Mute
Phase ........................ Normal/Reverse
Mid HPF/LPF:
Frequency (LPF) ... 1.6/2/2.5/3.15/4/5/6.3/8/10/
12.5/16 kHz
Frequency (HPF)
................................. 31.5/40/50/63/80/100/125/
160/200 Hz
Slope (LPF) ............. 0 (Pass)/6/12 dB/oct
Slope (HPF) ............ 0 (Pass)/6/12/18 dB/oct
Gain ............................ 0 24 dB/Mute
Phase ........................ Normal/Reverse
Low LPF:
Frequency ................ 31.5/40/50/63/80/100/125/
160/200 Hz
Slope .......................... 6/12/18 dB/oct
Gain ............................ +6 24 dB/Mute
Phase ........................ Normal/Reverse
CD player
System .......................................... Compact disc audio system
Usable discs .............................. Compact disc
Signal format:
Sampling frequency ..... 44.1 kHz
Number of quantization bits
........................................... 16; linear
Frequency characteristics ... 5 20,000 Hz (±1 dB)
Signal-to-noise ratio ............... 94 dB (1 kHz) (IEC-A net-
work)
Dynamic range ......................... 92 dB (1 kHz)
Number of channels .............. 2 (stereo)
MP3 decoding format ........... MPEG-1 & 2 Audio Layer 3
WMA decoding format ......... Ver. 7 & 8
MD player
System .......................................... Mini disc digital audio sys-
tem
Usable discs .............................. Mini disc
Signal format:
Sampling frequency ..... 44.1 kHz
Number of quantization bits
........................................... 16; linear
Frequency characteristics ... 20 20,000 Hz (±1 dB)
Signal-to-noise ratio ............... 90 dB (1 kHz) (IEC-A net-
work)
Dynamic range ......................... 90 dB (1 kHz)
Number of channels .............. 2 (stereo)
FM tuner
Frequency range ...................... 87.5 108.0 MHz
Usable sensitivity ..................... 8 dBf (0.7 µV/75 W, mono,
S/N: 30 dB)
50 dB quieting sensitivity ..... 10 dBf (0.9 µV/75 W, mono)
