9.3 Refurbishment Kits
9.3.1 GD30
9.3.2 GD50
NOTE: Each refurbishment kit includes; Coloured Cover Assembly, Case Assembly,
Key Sheet, Memo Key, LCD Panel, PCB Screw (x2), Cover Screw (x4), RF
Cap, Antenna and Patent Label.
9.4 Repair Jigs and Tools
D003 MA2S111TX DIODE MA2S111 80V 100mA SMD SS C4
DS001 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V F4
DS002 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V F3
DS003 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V E4
DS004 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V E3
DS005 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V D4
DS006 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V D3
DS007 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V D4
DS008 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V D3
DS009 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V C4
DS010 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V C4
DS011 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V C3
DS012 B3ABB0000066 DIODE LED GREEN 16-28mcd 2.2V C3
DS013 CL155URGDT 2 COLOUR LED 5V 25mA 3.2Lx2.7W A3
R001 EXB24V121JX RES NETWORK 120 OHMx2 5% 1/16W C3
R002 EXB24V151JX RES NETWORK 150 OHMx2 5% 1/16W C4
R003 EXB24V151JX RES NETWORK 150 OHMx2 5% 1/16W C3
R004 D0GB151JA002 RES 150 OHM 5% 1/10W SMD 1608 C3
R005 D0GB151JA002 RES 150 OHM 5% 1/10W SMD 1608 C3
R006 ERJ3EKF3003V RES 300K OHM 1% 1/16W SMD 1608 C4
R007 ERJ6ENF1204V RES 1.2M OHM 1% 1/10W SMD 2012 C4
R008 EXB24V151JX RES NETWORK 150 OHMx2 5% 1/16W C4
R009 EXB24V151JX RES NETWORK 150 OHMx2 5% 1/16W C4
R010 EXB24V121JX RES NETWORK 120 OHMx2 5% 1/16W C4
SHIELD GD30MDS030B GD30 RECEIVER SHIELD
Model: EB-GD30 & EB-DG50 Name: Keypad PCB
Ref. Part Number Description Grid
Model: EB-GD30 Name: Jigs and Tools
Ref. Part Number Description Notes
9R3000B REFURBISHMENT KIT, BLUE
9R3000K REFURBISHMENT KIT, BLACK
9R3000S REFURBISHMENT KIT, SILVER
Model: EB-GD50 Name: Jigs and Tools
Ref. Part Number Description Notes
9RD500B REFURBISHMENT KIT, BLUE
9RD500K REFURBISHMENT KIT, BLACK
9RD500N REFURBISHMENT KIT, GREEN
9RD500Y REFURBISHMENT KIT, GREY
Model: EB-GD30 Name: Jigs and Tools
Ref. Part Number Description Notes
IFB004 INTERFACE BOX
JT00009 GD30/GD50 RF ADAPTOR
JT00010 BATTERY CALIBRATION VOLT. CONTROL UNIT
JT00011 GD30/GD50 PCB REPAIR JIG
JT00022 TEST BATTERY
JT00004 INTERFACE CABLE
