Panasonic EB-GD30 - Manual (Page 83)

R
E
P
L
A
C
E
M
E
N
T
P
A
R
T
S
L
IS
T
M
C
U
K
9
9
1
0
0
1
C
8
S
e
c
tio
n
Is
s
u
e
1
S
e
rv
ic
e
M
a
n
u
a
l
–
7
7
–
R
e
v
is
io
n
0
R405 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005 E1
R406 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005 D1
R407 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005 D1
R408 ERJ2GEJ473X RES 47K OHM 5% 1/16W SMD 1005 E1
R409 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 E1
R410 ERJ2GEJ123X RES 12K OHM 5% 1/16W SMD 1005 E1
R411 D1BDR1500001 RESISTOR 0.15 OHM 1% 1/4W SMD D1
R412 ERJ6GEYJ330V RES 33 OHM 5% 1/10W SMD 2012 D1
R413 ERJ2GEJ153X RES 15K OHM 5% 1/16W SMD 1005 D1
R414 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 D1
R415 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 D1
R416 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 D1
R417 ERJ6GEYJ270V RES 27 OHM 5% 1/10W SMD 2012 C1
R418 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 D1
R419 ERJ6GEYJ560V RES 56 OHM 5% 1/10W SMD 2012 C1
R420 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005 E1
R421 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 E1
R502 ERJ2GEJ470X RES 47 OHM 5% 1/16W SMD 1005 E1
R503 ERJ2GEJ222X RES 2.2K OHM 5% 1/16W SMD 1005 B4
R504 ERJ2GEJ472X RES 4.7K OHM 5% 1/16W SMD 1005 B4
R505 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005 B4
R506 ERJ2GEJ223X RES 22K OHM 5% 1/16W SMD 1005 B4
R507 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005 E1
R508 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005 E2
R510 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005 C3
R511 ERJ2GEJ102X RES 1K OHM 5% 1/16W SMD 1005 E1
R512 ERJ2GEJ102X RES 1K OHM 5% 1/16W SMD 1005 B4
R513 ERJ2GEJ102X RES 1K OHM 5% 1/16W SMD 1005 E2
R604 ERJ2GEJ223X RES 22K OHM 5% 1/16W SMD 1005 D2
R605 EXB24V331JX RES NETWORK 330 OHMx2 5% 1/16W F2
R606 EXB24V122JX RES NETWORK 1.2K OHMx2 5% 1/16 F2
Model: EB-GD30 & EB-GD50 Name: Main PCB (Common Items)
Ref. Part Number Description Grid
R607 EXB24V331JX RES NETWORK 330 OHMx2 5% 1/16W F2
R701 ERJ2GEJ393X RES 39K OHM 5% 1/16W SMD 1005 B1
R702 ERJ2GEJ392X RES 3.9K OHM 5% 1/16W SMD 1005 B1
R703 ERJ2GEJ510X RES 51 OHM 5% 1/16W SMD 1005 B1
R705 ERJ2GEJ392X RES 3.9K OHM 5% 1/16W SMD 1005 B1
R706 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005 B2
R707 ERJ2GEJ100X RES 10 OHM 5% 1/16W SMD 1005 B2
R708 ERJ2GEF223X RES 22K OHM 1% 1/16W SMD 1005 B2
R709 ERJ2GEJ4R7X RES 4.7 OHM 5% 1/16W SMD 1005 E4
R710 ERJ2GEF682X RES 6.8K OHM 1% 1/16W SMD 1005 B2
R711 ERJ2GEF682X RES 6.8K OHM 1% 1/16W SMD 1005 B2
R712 ERJ2GEF222X RES 2.2K OHM 1% 1/16W SMD 1005 B2
R713 ERJ2GEF222X RES 2.2K OHM 1% 1/16W SMD 1005 B2
R714 ERJ2GEF222X RES 2.2K OHM 1% 1/16W SMD 1005 B2
R715 ERJ2GEF222X RES 2.2K OHM 1% 1/16W SMD 1005 B2
R716 ERJ2GEJ391X RES 390 OHM 5% 1/16W SMD 1005 E4
R719 ERJ2GEJ100X RES 10 OHM 5% 1/16W SMD 1005 E3
R720 ERJ2GEJ471X RES 470 OHM 5% 1/16W SMD 1005 E3
R723 ERJ2GEJ470X RES 47 OHM 5% 1/16W SMD 1005 B2
R724 ERJ2GEJ122X RES 1.2K OHM 5% 1/16W SMD 1005 F3
R725 ERJ2GEJ122X RES 1.2K OHM 5% 1/16W SMD 1005 F3
R726 ERJ2GEJ122X RES 1.2K OHM 5% 1/16W SMD 1005 F3
R727 ERJ2GEJ122X RES 1.2K OHM 5% 1/16W SMD 1005 F3
R800 ERJ2GEJ820X RES 82 OHM 5% 1/16W SMD 1005 A1
R801 ERJ2GEJ101X RES 100 OHM 5% 1/16W SMD 1005 A1
R802 ERJ2GEJ510X RES 51 OHM 5% 1/16W SMD 1005 A1
R803 ERJ2GEJ820X RES 82 OHM 5% 1/16W SMD 1005 A1
R804 ERJ2GEJ223X RES 22K OHM 5% 1/16W SMD 1005 F3
R805 ERJ2GEJ123X RES 12K OHM 5% 1/16W SMD 1005 F3
R806 ERJ2GEJ750X RES 75 OHM 5% 1/16W SMD 1005 A1
R807 ERJ2GEJ101X RES 100 OHM 5% 1/16W SMD 1005 A1
Model: EB-GD30 & EB-GD50 Name: Main PCB (Common Items)
Ref. Part Number Description Grid
