R
E
P
L
A
C
E
M
E
N
T
P
A
R
T
S
L
IS
T
M
C
U
K
9
9
1
0
0
1
C
8
S
e
c
tio
n
Is
s
u
e
1
S
e
rv
ic
e
M
a
n
u
a
l
–
7
3
–
R
e
v
is
io
n
0
C768 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD E4
C769 ECUE1H102KBQ CAP CER 1nF 10% 50V X7R SMD 10 E4
C770 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 E4
C771 ECUE1H100DCQ CAP CER 10pF +/-0.5pF 50V NP0 A1
C772 ECUE1H390JCQ CAP CER 39pF 5% 50V NP0 SMD 10 B2
C773 ECUE1H181JCQ CAP CER 180pF 5% 50V X7R SMD 1 B2
C774 ECUE1H181JCQ CAP CER 180pF 5% 50V X7R SMD 1 B2
C775 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 B2
C778 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B2
C779 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 E4
C780 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 E4
C781 ECUE1H471KBQ CAP CER 470pF 10% 50V X7R SMD B1
C782 ECUE1H100DCQ CAP CER 10pF +/-0.5pF 50V NP0 E3
C783 ECJ1VB1E273K CAP CER 27nF 10% 25V X7R SMD 1 B2
C784 ECUE1H101JCQ CAP CER 100pF 5% 50V NP0 SMD 1 E3
C785 ECUE1H010CCQ CAP CER 1pF +/-0.25pF 50V NP0 B1
C786 ECUE1H471KBQ CAP CER 470pF 10% 50V X7R SMD E3
C787 ECUE1H090DCQ CAP CER 9pF +/-0.5pF 50V NP0 S B1
C788 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD E4
C789 ECUE1H470JCQ CAP CER 47pF 5% 50V NP0 SMD 10 E4
C801 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 F4
C802 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 F4
C803 ECUE1H151JCQ CAP CER 150pF 5% 50V NP0 SMD 1 F3
C804 ECUE1H151JCQ CAP CER 150pF 5% 50V NP0 SMD 1 F4
C805 ECUE1H020CCQ CAP CER 2pF +/-0.25pF 50V NP0 F3
C806 ECUE1H020CCQ CAP CER 2pF +/-0.25pF 50V NP0 F3
C807 ECUE1H2R7CCQ CAP CER 2.7pF +/-0.25pF 50V NP F3
C808 ECUE1H030CCQ CAP CER 3pF +/-0.25pF 50V NP0 F3
C809 ECUE1H820JCQ CAP CER 82pF 5% 50V NP0 SMD 10 F4
C811 ECUE1H820JCQ CAP CER 82pF 5% 50V NP0 SMD 10 F4
C814 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B2
Model: EB-GD30 & EB-GD50 Name: Main PCB (Common Items)
Ref. Part Number Description Grid
C815 F3F1A1060002 CAP TANT 10uF 20% 10V SMD CASE B2
C816 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 A1
C820 F3F1A1060002 CAP TANT 10uF 20% 10V SMD CASE A1
C821 ECUE1H120JCQ CAP CER 12pF 5% 50V NP0 SMD 10 A1
C822 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 A2
C823 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 A2
C824 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 E4
C825 ECUE1H030CCQ CAP CER 3pF +/-0.25pF 50V NP0 B2
C826 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 B2
C827 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 E4
C832 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 E4
C833 ECUE1H100DCQ CAP CER 10pF +/-0.5pF 50V NP0 E4
C834 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F3
C835 ECUE1H020CCQ CAP CER 2pF +/-0.25pF 50V NP0 B2
C900 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 C1
C901 ECST0JZ106R CAP TANT 10uF 20% 6.3V SMD CAS C2
C902 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 D4
C903 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 D4
C904 F3F1C475A004 CAP TANT 4.7uF 20% 16V SMD CAS C2
C906 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 C1
C907 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 C1
C908 ECUE1H470JCQ CAP CER 47pF 5% 50V NP0 SMD 10 B2
C909 ECUE1H030CCQ CAP CER 3pF +/-0.25pF 50V NP0 C1
C910 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 C1
C911 ECST0JZ106R CAP TANT 10uF 20% 6.3V SMD CAS C1
C912 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 B1
C913 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 C1
C914 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 C1
C915 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 C1
C916 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 C1
C917 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 C1
Model: EB-GD30 & EB-GD50 Name: Main PCB (Common Items)
Ref. Part Number Description Grid
