Panasonic EB-GD30 - Manual (Page 82)

R
E
P
L
A
C
E
M
E
N
T
P
A
R
T
S
L
IS
T
Is
s
u
e
1
S
e
c
tio
n
M
C
U
K
9
9
1
0
0
1
C
8
R
e
v
is
io
n
0
–
7
6
–
S
e
rv
ic
e
M
a
n
u
a
l
L730 ELJRF8N2JF2 INDUCTOR 8.2nH 5% SMD 1005 E4
L731 ELJRF18NJF2 INDUCTOR 18nH 5% SMD 1005 F3
L732 G1C5N6Z00005 INDUCTOR 5.6nH +/-0.3nH SMD 10 F3
L733 ELJRF18NJF2 INDUCTOR 18nH 5% SMD 1005 B2
L734 ELJRF18NJF2 INDUCTOR 18nH 5% SMD 1005 B1
L800 G1C4N7Z00004 INDUCTOR 4.7nH +/-0.3nH SMD 10 F3
L801 G1C15NJ00008 INDUCTOR 15nH 5% SMD 1005 F3
L804 G1C5N6Z00005 INDUCTOR 5.6nH +/-0.3nH SMD 10 E4
L807 ELJRF22NJF2 INDUCTOR 22nH 5% SMD 1005 E4
L808 G1C15NJ00008 INDUCTOR 15nH 5% SMD 1005 B2
L809 G1C15NJ00008 INDUCTOR 15nH 5% SMD 1005 B2
L900 ELJRF6N8JF2 INDUCTOR 6.8nH 5% SMD 1005 C2
L901 ELJRF8N2JF2 INDUCTOR 8.2nH 5% SMD 1005 C2
L902 ELJRF22NJF2 INDUCTOR 22nH 5% SMD 1005 D4
LS900 HB76004B BUZZER GD90 F4
P100 PY76018A CONNECTOR BOARD TO BOARD 2x16 D1
Q101 B1GFCFEM0001 TRANSISTOR UMH10TN DUAL NPN WI F2
Q102 B1ABCB000024 TRANSISTOR 2SC4226 NPN SMD SOT C2
Q401 2SD2216TX TRANSISTOR 2SD2216TX NPN SMD S E1
Q402 B1DHCC000012 TRANSISTOR SI3441DV MOSFET -20 E1
Q403 B1GKGFBJ0001 TRANSISTOR IMD14 DUAL SMD SMT6 C1
Q404 B1GKGFBJ0001 TRANSISTOR IMD14 DUAL SMD SMT6 C1
Q405 B1CFJC000001 TRANSISTOR FDG6301N DUAL N-CH E1
Q406 B1ADPC000003 TRANSISTOR 2SB1424T100R PNP SM E1
Q501 B1GKCFLL0006 TRANSISTOR UMD2N DUAL SMD UMT6 F2
Q700 B1GKCFNE0001 TRANSISTOR RN4905 DUAL NPN PNP B1
Q701 B1GKCFNE0001 TRANSISTOR RN4905 DUAL NPN PNP B2
Q702 B1GKCFLL0006 TRANSISTOR UMD2N DUAL SMD UMT6 F3
Q703 B1GFCFEM0001 TRANSISTOR UMH10TN DUAL NPN WI
Q800 B1GKCFNE0001 TRANSISTOR RN4905 DUAL NPN PNP E4
Q801 XP0431200L TRANSISTOR XP4312 DUAL NPN PNP A2
Model: EB-GD30 & EB-GD50 Name: Main PCB (Common Items)
Ref. Part Number Description Grid
Q900 2SD1511RSTX TRANSISTOR 2SD1511RSTX NPN HFE C1
Q901 B1GKCFNE0001 TRANSISTOR RN4905 DUAL NPN PNP
R101 ERJ2GEJ102X RES 1K OHM 5% 1/16W SMD 1005 F2
R102 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 F2
R103 ERJ2GEJ331X RES 330 OHM 5% 1/16W SMD 1005 F2
R104 EXB24V331JX RES NETWORK 330 OHMx2 5% 1/16W F2
R105 EXB24V331JX RES NETWORK 330 OHMx2 5% 1/16W F1
R106 ERJ2GEJ332X RES 3.3K OHM 5% 1/16W SMD 1005 F2
R107 ERJ3GEYF104V RES 100K OHM 1% 1/16W SMD 1608 F1
R108 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 E1
R109 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 F2
R110 ERJ2GEJ331X RES 330 OHM 5% 1/16W SMD 1005 F2
R111 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005
R112 ERJ2GEJ472X RES 4.7K OHM 5% 1/16W SMD 1005 E1
R113 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 A4
R114 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 B2
R115 ERJ2GEJ472X RES 4.7K OHM 5% 1/16W SMD 1005 D2
R116 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005 C4
R117 ERJ2GEJ101X RES 100 OHM 5% 1/16W SMD 1005 C4
R118 ERJ2GEJ682X RES 6.8K OHM 5% 1/16W SMD 1005 C4
R119 ERJ2GEJ221X RES 220 OHM 5% 1/16W SMD 1005 D2
R120 ERJ2GEJ681X RES 680 OHM 5% 1/16W SMD 1005 D2
R121 ERJ2GEJ223X RES 22K OHM 5% 1/16W SMD 1005 C2
R122 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 C4
R123 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 D4
R124 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 D4
R125 EXB24V331JX RES NETWORK 330 OHMx2 5% 1/16W F2
R126 EXB24V331JX RES NETWORK 330 OHMx2 5% 1/16W F1
R401 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005 D1
R403 ERJ2GEJ104X RES 100K OHM 5% 1/16W SMD 1005 B3
R404 ERJ2GEJ103X RES 10K OHM 5% 1/16W SMD 1005 F1
Model: EB-GD30 & EB-GD50 Name: Main PCB (Common Items)
Ref. Part Number Description Grid
