Panasonic EB-GD30 - Manual (Page 78)

R
E
P
L
A
C
E
M
E
N
T
P
A
R
T
S
L
IS
T
Is
s
u
e
1
S
e
c
tio
n
M
C
U
K
9
9
1
0
0
1
C
8
R
e
v
is
io
n
0
–
7
2
–
S
e
rv
ic
e
M
a
n
u
a
l
C608 ECUE1H100DCQ CAP CER 10pF +/-0.5pF 50V NP0 C2
C618 ECST0JZ106R CAP TANT 10uF 20% 6.3V SMD CAS F2
C619 F1G1A104A012 CAP CER 100nF 10% 10V X5R SMD F2
C620 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10
C621 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 A4
C622 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 E2
C623 YCCIX024K333 CAP CER 33nF 10% 10V X5R SMD 1 E2
C624 YCCIX024K333 CAP CER 33nF 10% 10V X5R SMD 1 E2
C625 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F2
C626 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F2
C627 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F2
C628 YCCIX027K223 CAP CER 22nF 10% 16V X7R SMD 1 F2
C700 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B1
C701 ECUE1H391KBQ CAP CER 390pF 10% 50V X7R SMD B1
C702 ECUE1H471KBQ CAP CER 470pF 10% 50V X7R SMD E3
C703 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B1
C704 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B1
C705 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B1
C706 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 B1
C707 ECUE1H020CCQ CAP CER 2pF +/-0.25pF 50V NP0 E3
C708 ECUE1H010CCQ CAP CER 1pF +/-0.25pF 50V NP0 E3
C709 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 B1
C710 ECUE1H020CCQ CAP CER 2pF +/-0.25pF 50V NP0 B1
C711 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 B1
C712 ECUE1H470JCQ CAP CER 47pF 5% 50V NP0 SMD 10 B1
C715 ECUE1H101JCQ CAP CER 100pF 5% 50V NP0 SMD 1 B1
C716 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 B1
C717 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 B1
C718 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B1
C721 ECUE1H010CCQ CAP CER 1pF +/-0.25pF 50V NP0 B1
C722 ECUE1H040CCQ CAP CER 4pF +/-0.25pF 50V NP0 E3
Model: EB-GD30 & EB-GD50 Name: Main PCB (Common Items)
Ref. Part Number Description Grid
C723 ECUE1H040CCQ CAP CER 4pF +/-0.25pF 50V NP0 E3
C724 ECUE1H101JCQ CAP CER 100pF 5% 50V NP0 SMD 1 A1
C725 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 B1
C728 ECUE1H0R5CCQ CAP CER 0.5pF +/-0.25pF 50V NP B1
C729 ECUE1H030CCQ CAP CER 3pF +/-0.25pF 50V NP0 B1
C733 ECUE1H080DCQ CAP CER 8pF +/-0.5pF 50V NP0 S B1
C734 ECUE1H470JCQ CAP CER 47pF 5% 50V NP0 SMD 10 B1
C735 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B1
C736 ECUE1H101JCQ CAP CER 100pF 5% 50V NP0 SMD 1 F3
C737 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 F3
C738 ECUE1H020CCQ CAP CER 2pF +/-0.25pF 50V NP0 B1
C739 ECUE1H102KBQ CAP CER 1nF 10% 50V X7R SMD 10 B1
C740 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B1
C743 ECUE1H102KBQ CAP CER 1nF 10% 50V X7R SMD 10 B1
C744 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B1
C745 ECUE1H470JCQ CAP CER 47pF 5% 50V NP0 SMD 10 B1
C748 ECUE1H020CCQ CAP CER 2pF +/-0.25pF 50V NP0 B1
C749 ECUE1H100DCQ CAP CER 10pF +/-0.5pF 50V NP0 E4
C750 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F3
C751 ECUE1H100DCQ CAP CER 10pF +/-0.5pF 50V NP0 E4
C752 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 A1
C753 F1G1A104A012 CAP CER 100nF 10% 10V X5R SMD B2
C754 ECUE1H220JCQ CAP CER 22pF 5% 50V NP0 SMD 10 B1
C755 ECUE1H470JCQ CAP CER 47pF 5% 50V NP0 SMD 10 B1
C760 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F3
C761 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 A1
C762 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 A1
C763 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F3
C764 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 B2
C766 ECUE1H101JCQ CAP CER 100pF 5% 50V NP0 SMD 1 F3
C767 ECUE1H100DCQ CAP CER 10pF +/-0.5pF 50V NP0 A1
Model: EB-GD30 & EB-GD50 Name: Main PCB (Common Items)
Ref. Part Number Description Grid
