9.2 Printed Circuit Boards (PCBs)
9.2.1 Main PCB: Variants
9.2.2 Main PCB: Common Items
Model: EB-GD30 & EB-GD50 Name: Main PCB (Variants)
Ref.
Part Number
Description
GD30 GD50
003 GD30BRD001 GD50BRD001 MAIN PCB STANDARD PROGRAM
003 GD30BRD002 GD50BRD002 MAIN PCB BINARING PROGRAM
003 GD30BRD003 GD50BRD003 MAIN PCB CELCOM PROGRAM
003 GD30BRD004 GD50BRD004 MAIN PCB AIRTEL PROGRAM
003 GD30BRD005 GD50BRD005 MAIN PCB EUROTEL PROGRAM
003 GD30BRD006 GD50BRD006 MAIN PCB MOVISTAR PROGRAM
003 GD30BRD007 GD50BRD007 MAIN PCB S.F.R PROGRAM
003 GD30BRD008 GD50BRD008 MAIN PCB WESTEL PROGRAM
003 GD30BRD009 GD50BRD009 MAIN PCB HUTCHISON PROGRAM
003 GD30BRD010 GD50BRD010 MAIN PCB PLUS GSM PROGRAM
003 GD30BRD011 GD50BRD011 MAIN PCB TURKCELL PROGRAM
003 GD30BRD012 GD50BRD012 MAIN PCB FRANCETEL PROGRAM
003 GD30BRD013 GD50BRD013 MAIN PCB FT FTMS PROGRAM
003 GD30BRD014 GD50BRD014 MAIN PCB TELESTET PROGRAM
003 GD30BRD015 GD50BRD015 MAIN PCB ACTIVA PROGRAM
003 GD30BRD016 GD50BRD016 MAIN PCB TMN PROGRAM
003 GD30BRD017 GD50BRD017 MAIN PCB PANNON PROGRAM
003 GD30BRD018 GD50BRD018 MAIN PCB VODACOM PROGRAM
003 GD30BRD019 GD50BRD019 MAIN PCB NETCOM PROGRAM
003 GD30BRD020 GD50BRD020 MAIN PCB K.P.N PROGRAM
003 GD30BRD021 GD50BRD021 MAIN PCB MOBILCOM PROGRAM
003 GD30BRD022 GD50BRD022 MAIN PCB TELSTRA PROGRAM
003 GD30BRD023 GD50BRD023 MAIN PCB E.R.A PROGRAM
003 GD30BRD024 GD50BRD024 MAIN PCB PAYT VODAFONE PROGRAM
003 GD30BRD025 GD50BRD025 MAIN PCB CHINESE ENABLED PROGRAM
Model: EB-GD30 & EB-GD50 Name: Main PCB (Common Items)
Ref. Part Number Description Grid
C101 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD F2
C102 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F2
C103 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD F2
C104 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD E2
C105 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD F2
C106 F1G1A104A012 CAP CER 100nF 10% 10V X5R SMD F2
C107 F1G1A104A012 CAP CER 100nF 10% 10V X5R SMD F1
C108 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F2
C109 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F2
C110 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 E2
C111 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 F2
C112 F1G1A104A012 CAP CER 100nF 10% 10V X5R SMD F1
C113 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD F2
C114 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD F2
C115 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD F1
C116 ECUE1H102KBQ CAP CER 1nF 10% 50V X7R SMD 10 F1
C117 ECUE1H102KBQ CAP CER 1nF 10% 50V X7R SMD 10 F2
C118 ECUE1H331KBQ CAP CER 330pF 10% 50V X7R SMD
C119 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 E2
C120 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 E2
C122 F1H1A4740005 CAP CER 470nF 10% 10V X5R SMD E2
C123 ECUE1H102KBQ CAP CER 1nF 10% 50V X7R SMD 10 C2
C124 ECUE1H101JCQ CAP CER 100pF 5% 50V NP0 SMD 1 C2
C125 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 C2
C127 ECUE1H040CCQ CAP CER 4pF +/-0.25pF 50V NP0 C2
C128 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 D4
C129 ECUE1H330JCQ CAP CER 33pF 5% 50V NP0 SMD 10 D4
C130 ECUE1H030CCQ CAP CER 3pF +/-0.25pF 50V NP0 D4
C131 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1 C4
C132 ECUE1H101JCQ CAP CER 100pF 5% 50V NP0 SMD 1 C4
